The S7000 CD/HCP4A is a super precision angular contact ball bearing with a 10mm bore and 26mm outer diameter, crafted from chrome steel and ceramic balls. It handles radial loads up to 922 lbf and spins at speeds up to 90,000 RPM.
Its sealed design keeps lubrication in and contaminants out, while the phenolic cage ensures smooth operation. The 15° contact angle and P4 tolerance class make it ideal for high-precision applications.
This bearing is available with preload and matched arrangements for enhanced performance. Perfect for use in machine tools or high-speed spindles where accuracy is key.
Weighing just 0.017kg, it’s lightweight yet durable. It operates smoothly in temperatures from -30°C to 110°C, making it versatile for various environments.
"*" indicates required fields
Why Choose S7000 CD/HCP4A Bearing for Precision Tasks?
S7000 CD/HCP4A Bearing features a 15° contact angle, ideal for high-precision angular contact applications.
Its ceramic balls and chrome steel rings ensure smooth operation with minimal friction.
The phenolic cage maintains ball alignment, enhancing durability and performance.
With a maximum speed of 90,000 rpm, it excels in high-speed environments.
S7000 CD/HCP4A Bearing’s P4 tolerance class guarantees exceptional accuracy for demanding tasks.
Its preload and matched arrangement options provide flexibility for various applications.
Perfect Fit for Automation: S7000 CD/HCP4A Bearing
S7000 CD/HCP4A Bearing is commonly used in industrial robots, where its precision angular contact design ensures smooth movement in mechanical arms. The ceramic balls reduce friction, making it ideal for high-speed operations.
How Does S7000 CD/HCP4A Bearing Improve Performance?
In automotive applications, S7000 CD/HCP4A Bearing enhances the efficiency of electric motors and gearboxes. Its sealed design keeps contaminants out, extending the lifespan of critical components.
Medical vs Industrial: Where S7000 CD/HCP4A Bearing Excels
For medical devices like surgical robots, S7000 CD/HCP4A Bearing offers reliable performance due to its phenolic cage and P4 tolerance. In industrial settings, it’s favoured for spindle drives where accuracy is key.
Built for Heavy-Duty Use: S7000 CD/HCP4A Bearing
S7000 CD/HCP4A Bearing handles demanding conditions in machine tools, thanks to its chrome steel rings and high dynamic load capacity. The lubricated design ensures consistent performance even under continuous use.
