The 7018 ACE/HCP4AH1DT is a super precision angular contact ball bearing with a 90mm bore and 140mm outer diameter, designed for high-performance applications. Its 25° contact angle and ceramic balls ensure smooth operation under heavy radial loads up to 12442 lbf.
The open design and phenolic cage allow for easy lubrication and reduced friction, supporting speeds up to 15000 RPM. The matched pair arrangement with preload enhances stability in demanding setups.
Ideal for machine tools or high-speed spindles, this bearing operates reliably between -30°C and 110°C. Its P4A tolerance class guarantees precise alignment and long service life.
Weighing 2.22kg, it’s a robust choice for industrial machinery. The bearing is interchangeable with SKF models, offering flexibility for replacements.
"*" indicates required fields
Performance Features of 7018 ACE/HCP4AH1DT Bearing
7018 ACE/HCP4AH1DT Bearing is designed with a 25° contact angle, optimising load distribution for angular contact applications.
The chrome steel rings and ceramic balls enhance durability and reduce friction during high-speed operation.
With a dynamic radial load capacity of 12442 lbf, it handles demanding tasks efficiently.
The phenolic cage ensures smooth movement and alignment of the 28 ceramic balls.
Operating at speeds up to 15,000 rpm, 7018 ACE/HCP4AH1DT Bearing maintains precision in various conditions.
Its matched arrangement of two bearings provides stability and consistent performance.
The open seal design allows easy lubrication, extending the bearing’s service life.
Its temperature range of -30°C to 110°C ensures reliability in diverse environments.
Industrial Uses of 7018 ACE/HCP4AH1DT Bearing
7018 ACE/HCP4AH1DT Bearing is commonly used in high-speed machine tools, where its precision angular contact design ensures accurate spindle performance. The ceramic balls reduce friction, making it ideal for applications requiring smooth rotation.
In robotics, 7018 ACE/HCP4AH1DT Bearing supports articulated arms, providing stability and load capacity for repetitive movements. Its matched arrangement simplifies installation in complex assemblies.
For aerospace components, 7018 ACE/HCP4AH1DT Bearing’s phenolic cage offers lightweight durability, crucial for reducing overall system weight. The P4A tolerance class guarantees consistent performance in demanding conditions.
Automotive vs Aerospace: Applications of 7018 ACE/HCP4AH1DT Bearing
In automotive systems, 7018 ACE/HCP4AH1DT Bearing enhances performance in gearboxes, handling both radial and axial loads efficiently. Its lubricated design ensures longevity even under continuous use.
Aerospace applications benefit from 7018 ACE/HCP4AH1DT Bearing’s ability to withstand extreme temperatures and high speeds. The ceramic balls minimise wear, making it reliable for critical flight components.
What Makes 7018 ACE/HCP4AH1DT Bearing a Preferred Choice?
7018 ACE/HCP4AH1DT Bearing is favoured in medical imaging devices for its quiet operation and precision. The chrome steel rings provide durability, while the open seal allows for easy maintenance.
In automation lines, 7018 ACE/HCP4AH1DT Bearing ensures smooth movement in conveyor systems. Its preload capability reduces vibration, improving overall system accuracy.
