Stainless Steel Deep Groove Ball Bearings W 634-2Z
Stainless Steel Deep Groove Ball Bearings W 634-2Z

Stainless Steel Deep Groove Ball Bearings W 634-2Z

The W 634-2Z is a compact stainless steel deep groove ball bearing, measuring 4mm by 16mm by 5mm. It handles radial loads up to 171 lbf and spins smoothly at speeds up to 50,000 RPM.

Its shielded design keeps dirt out while retaining grease, making it low-maintenance. The all-stainless construction ensures good corrosion resistance for damp or washdown environments.

This model works in temperatures from -30°C to 120°C and comes pre-lubricated with grease. It’s interchangeable with SKF bearings for easy replacement.

Weighing just 5.2 grams, it’s ideal for small machinery, medical devices, or food processing equipment where hygiene matters. Compliant with RoHS and REACH standards.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number W 634-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 4 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 16 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 5 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 171 lbf
  • Static Radial Load 60 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 50000 rpm
  • Weight 0.0052 kg
  • Price($) 2.76

Features

Engineered for Precision: W 634-2Z Bearing

W 634-2Z Bearing features stainless steel construction, offering excellent resistance to corrosion and wear.
Its compact size of 4 mm×16 mm×5 mm makes it ideal for applications where space is limited.

The shielded design protects against contaminants while maintaining smooth operation.
With a maximum speed of 50,000 rpm, it delivers reliable performance in high-speed scenarios.

W 634-2Z Bearing’s dynamic radial load capacity of 171 lbf ensures durability under stress.
Its grease lubrication reduces maintenance needs, making it a practical choice for various industries.

Application

Key Fields for W 634-2Z Bearing
W 634-2Z Bearing is commonly used in small electric motors and precision instruments due to its compact size and shielded design, which keeps contaminants out. Its stainless steel construction makes it suitable for environments where corrosion resistance is important.

In consumer electronics like printers and small fans, W 634-2Z Bearing ensures quiet and smooth operation. The grease lubrication helps maintain performance over time without frequent maintenance.

For medical devices such as dental tools or lab equipment, W 634-2Z Bearing’s reliability and low friction are key. The metric dimensions allow it to fit seamlessly into various European and Asian designs.

Automation systems benefit from W 634-2Z Bearing’s ability to handle high speeds, making it ideal for robotic arms and small conveyors. The P0 tolerance ensures consistent performance in precise applications.
