Stainless Steel Deep Groove Ball Bearings W 6300
Stainless Steel Deep Groove Ball Bearings W 6300

Stainless Steel Deep Groove Ball Bearings W 6300

The W 6300 is a stainless steel deep groove ball bearing with a 10mm bore and 35mm outer diameter, designed for radial loads. It handles dynamic loads up to 1578 lbf and spins smoothly at speeds up to 34,000 RPM.

Its open design allows for easy lubrication, while the all-stainless steel construction ensures corrosion resistance. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like food processing or marine equipment where rust resistance is key.

Weighing just 0.05kg, it’s lightweight yet durable for its size. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number W 6300
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 35 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 11 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 1578 lbf
  • Static Radial Load 764 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 34000 rpm
  • Weight 0.05 kg

Features

Why Choose W 6300 Bearing for Precision Tasks?

W 6300 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its single-row design ensures smooth radial load handling, making it ideal for precision applications.

With a dynamic radial load capacity of 1578 lbf, W 6300 Bearing performs reliably under stress.
The open seal type allows for easy maintenance while maintaining high-speed performance up to 34,000 rpm.

W 6300 Bearing operates efficiently in temperatures ranging from -30° to 120°C.
Its lightweight design at just 0.05 kg ensures easy integration into various systems.

Application

Industrial Uses of W 6300 Bearing
W 6300 Bearing is commonly used in industrial settings, such as conveyor systems and small electric motors, where its stainless steel construction offers good resistance to corrosion. Its open design allows for easy lubrication, making it suitable for environments with varying operational demands.

In automotive applications, W 6300 Bearing can be found in components like alternators and water pumps, where its radial load capacity ensures reliable performance. The metric sizing ensures compatibility with a wide range of vehicle models.

For household appliances, W 6300 Bearing is often used in fans and small power tools, where its smooth operation and durability are appreciated. The stainless steel materials help it withstand daily wear and tear.

In medical devices, W 6300 Bearing provides consistent performance in equipment like dental handpieces, where precision and hygiene are important. Its corrosion-resistant properties make it ideal for frequent cleaning and sterilisation.

Automation systems benefit from W 6300 Bearing in robotic arms and small actuators, where its low friction and high-speed capabilities are advantageous. The lightweight design also contributes to energy efficiency in continuous operations.
