Stainless Steel Deep Groove Ball Bearings W 6201
Stainless Steel Deep Groove Ball Bearings W 6201

Stainless Steel Deep Groove Ball Bearings W 6201

The W 6201 is a stainless steel deep groove ball bearing with a 12mm bore and 32mm outer diameter, designed for radial loads. It handles dynamic loads up to 1286 lbf and spins smoothly at speeds up to 34,000 RPM.

Made entirely from stainless steel, it resists corrosion and lasts longer in harsh conditions. The open design allows for easy lubrication and maintenance.

With a compact width of 10mm, it fits neatly into tight spaces. Ideal for applications like food processing equipment or marine environments where rust resistance is key.

Weighing just 0.034kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, making it a safe choice for various industries.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number W 6201
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 10 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 1286 lbf
  • Static Radial Load 674 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 34000 rpm
  • Weight 0.034 kg

Features

How Does W 6201 Bearing Reduce Friction?

W 6201 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its stainless steel construction ensures low friction and quiet operation, even at high speeds.

The bearing’s open design allows for easy lubrication, enhancing performance and longevity.
With a maximum speed of 34,000 rpm, it is ideal for applications requiring efficiency and reliability.

Application

Industrial Uses of W 6201 Bearing
W 6201 Bearing is commonly used in industrial settings, such as conveyor systems and small electric motors, where its stainless steel construction offers good resistance to corrosion. The open design allows for easy lubrication, ensuring smooth operation in dusty environments.

How Does W 6201 Bearing Improve Performance?
In automotive applications, W 6201 Bearing helps reduce friction in components like alternators and water pumps, enhancing efficiency. Its metric size makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: W 6201 Bearing
W 6201 Bearing works well in robotic arms and 3D printers, where precision and reliability are key. The stainless steel balls and cage ensure durability even with frequent use.

Medical vs Industrial: Where W 6201 Bearing Excels
For medical devices like dental tools, W 6201 Bearing provides quiet and smooth operation. In industrial equipment, it handles radial loads effectively, making it a dependable option.

Where Is W 6201 Bearing Used?
You’ll find W 6201 Bearing in household appliances like fans and small power tools, where its compact size and durability are ideal. The stainless steel material also makes it suitable for damp environments.
