The 6309-2RSNRJEM is a sealed single-row ball bearing with a 45mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.
Its snap ring groove on the outer ring ensures secure fitting, while the sealed design keeps out contaminants for longer life. The bearing performs well in temperatures from -30°C to 120°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads and secure mounting are key.
Weighing 811g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of 6309-2RSNRJEM Bearing
6309-2RSNRJEM Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 11915 lbf, ensuring reliable performance in various applications.
The sealed design protects against contaminants, making it suitable for harsh environments.
With a maximum speed of 6,700 rpm, it balances durability and efficiency.
How Is 6309-2RSNRJEM Bearing Engineered for Reliability?
6309-2RSNRJEM Bearing features a snap ring groove for secure mounting, enhancing stability during operation.
The chrome steel cage maintains ball alignment, reducing wear and extending service life.
Its sealed construction prevents dirt and moisture ingress, ensuring smooth performance.
The bearing operates efficiently within a temperature range of -30° to 120°C.
Optimized for Efficiency: 6309-2RSNRJEM Bearing
6309-2RSNRJEM Bearing’s single-row design provides consistent radial load support.
The ABEC 1 tolerance ensures precise operation, suitable for general applications.
Its snap ring groove simplifies installation, saving time and effort.
The bearing’s weight of 811 g makes it easy to handle without compromising strength.
Steel vs Ceramic Bearings: Strengths of 6309-2RSNRJEM Bearing
6309-2RSNRJEM Bearing uses chrome steel for all components, ensuring durability and cost-effectiveness.
The material choice provides excellent resistance to wear and tear in demanding conditions.
Its sealed design offers added protection compared to open bearings.
With a static radial load capacity of 7194 lbf, it handles heavy loads reliably.
Key Fields for 6309-2RSNRJEM Bearing
6309-2RSNRJEM Bearing works well in industrial settings, especially for conveyor belts and pumps where radial loads are common. Its sealed design keeps out dust and debris, reducing maintenance needs.
In automotive applications, 6309-2RSNRJEM Bearing fits nicely in wheel hubs and transmissions. The snap ring feature ensures a secure fit, even under constant vibration.
For home appliances like washing machines, 6309-2RSNRJEM Bearing offers quiet and smooth operation. The chrome steel construction provides long-lasting performance in everyday use.
Robotic arms often use 6309-2RSNRJEM Bearing for precise movement. Its sealed nature protects internal components from contamination in sensitive environments.
Medical devices benefit from 6309-2RSNRJEM Bearing’s reliable performance. The consistent operation is key for equipment like centrifuges and diagnostic machines.
