The 6306-2RSNR/C3 VT228 is a sealed, single-row ball bearing with a 30mm bore and 72mm outer diameter, designed for radial loads. It handles dynamic loads up to 6002 lbf and operates smoothly at speeds up to 9600 RPM.
Its snap ring groove on the outer ring ensures secure fitting, while the sealed design keeps dirt out and lubrication in. Made from durable chrome steel, it’s built to last in tough conditions.
This bearing is ideal for machinery where reliable radial load support is needed, such as electric motors or conveyor systems. It works in temperatures from -30°C to 120°C.
Weighing 346g, it’s a sturdy yet manageable size. Compliant with RoHS and REACH standards, it’s a safe choice for various industrial applications. Interchangeable with SKF bearings for easy replacement.
"*" indicates required fields
How Is 6306-2RSNR/C3 VT228 Bearing Engineered for Reliability?
6306-2RSNR/C3 VT228 Bearing features a sealed design, protecting against contaminants and extending its service life.
The chrome steel construction ensures durability and resistance to wear, even under heavy radial loads.
With a dynamic radial load capacity of 6002 lbf, it performs reliably in demanding applications.
Its snap ring outer ring design simplifies installation and enhances stability during operation.
Performance Features of 6306-2RSNR/C3 VT228 Bearing
6306-2RSNR/C3 VT228 Bearing operates smoothly at speeds up to 9,600 rpm, making it suitable for high-speed applications.
The C3 radial clearance allows for thermal expansion, ensuring consistent performance in varying temperatures.
Its sealed design reduces the need for frequent maintenance, lowering operational costs.
The chrome steel cage and balls provide excellent resistance to wear and tear.
Why Choose 6306-2RSNR/C3 VT228 Bearing for Precision Tasks?
6306-2RSNR/C3 VT228 Bearing’s ABEC 1 tolerance class ensures precise and reliable operation.
The snap ring feature on the outer ring offers secure mounting, reducing the risk of misalignment.
Its temperature range of -30° to 120°C makes it versatile for various industrial environments.
The sealed design keeps lubrication intact, ensuring long-term smooth performance.
Designed for Durability: 6306-2RSNR/C3 VT228 Bearing
6306-2RSNR/C3 VT228 Bearing’s chrome steel components provide excellent resistance to corrosion and wear.
Its static radial load capacity of 3372 lbf ensures reliability in heavy-duty applications.
The sealed construction protects against dust and moisture, enhancing its lifespan.
With a weight of 346 g, it offers a balance of strength and lightweight design.
Industrial Uses of 6306-2RSNR/C3 VT228 Bearing
The 6306-2RSNR/C3 VT228 Bearing is commonly used in conveyor systems, where its sealed design keeps out dust and debris. Its snap ring feature ensures secure mounting, reducing maintenance downtime.
Where Is 6306-2RSNR/C3 VT228 Bearing Used?
You’ll often find 6306-2RSNR/C3 VT228 Bearing in electric motors, thanks to its reliable radial load handling. The C3 clearance allows for thermal expansion, making it suitable for variable-speed applications.
Built for Heavy-Duty Use: 6306-2RSNR/C3 VT228 Bearing
This bearing works well in agricultural machinery, where its chrome steel construction resists wear. The sealed design also helps protect against moisture in outdoor environments.
Automotive vs Industrial: Applications of 6306-2RSNR/C3 VT228 Bearing
In automotive fans, 6306-2RSNR/C3 VT228 Bearing offers smooth rotation with minimal noise. For industrial pumps, its high-speed capability ensures consistent performance under load.
Perfect Fit for Automation: 6306-2RSNR/C3 VT228 Bearing
The 6306-2RSNR/C3 VT228 Bearing is ideal for robotic arms, where precision and durability are key. Its snap ring simplifies installation, saving time during assembly.
