The 6305-2RS1NR is a snap ring groove ball bearing with a 25mm bore and 62mm outer diameter, measuring 17mm in width. Made from durable chrome steel, it’s built to handle radial loads up to 4631 lbf.
Its sealed design keeps out dust and dirt, while the snap ring on the outer ring ensures secure fitting. The bearing can reach speeds of up to 11000 RPM, making it suitable for fast-moving applications.
With a temperature range of -30°C to 120°C, it performs well in various environments. The chrome steel cage adds to its longevity and smooth operation.
Ideal for machinery where radial loads and secure mounting are key, such as electric motors or conveyor systems. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, especially as it’s interchangeable with SKF bearings.
"*" indicates required fields
How Does 6305-2RS1NR Bearing Reduce Friction?
6305-2RS1NR Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
The sealed design helps retain lubrication, further reducing wear and extending its service life.
Its dynamic radial load capacity of 4631 lbf makes it suitable for various applications.
The snap ring groove on the outer ring provides secure positioning, enhancing stability during operation.
With a maximum speed of 11,000 rpm, it delivers reliable performance in demanding conditions.
The ABEC 1 tolerance class ensures consistent precision for everyday use.
Essential Roles of 6305-2RS1NR Bearing
In industrial settings, 6305-2RS1NR Bearing is commonly used in conveyor systems and electric motors, where its sealed design protects against dust and debris. The snap ring feature ensures secure mounting, reducing maintenance needs.
How Does 6305-2RS1NR Bearing Improve Performance?
For automotive applications like alternators and pumps, 6305-2RS1NR Bearing offers reliable radial load support. Its chrome steel construction provides durability, even in high-temperature environments.
Perfect Fit for Automation: 6305-2RS1NR Bearing
In robotic arms and automated machinery, 6305-2RS1NR Bearing’s smooth operation and sealed design enhance precision. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.
Medical vs Industrial: Where 6305-2RS1NR Bearing Excels
While 6305-2RS1NR Bearing is versatile for industrial gear, it also suits medical devices like centrifuges. Its sealed construction prevents contamination, crucial for sterile environments.
Where to Use 6305-2RS1NR Bearing
In household appliances like washing machines, 6305-2RS1NR Bearing’s durability and low maintenance make it a practical choice. The snap ring simplifies installation, saving time during repairs.
