The 6014NR/C3 is a snap ring groove ball bearing with a 70mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8565 lbf and operates smoothly at speeds reaching 6000 RPM.
Its open design and snap ring feature on the outer ring ensure easy installation and secure positioning. The C3 radial clearance allows for slight thermal expansion, making it adaptable to varying conditions.
This bearing is interchangeable with SKF models, offering a reliable alternative for replacements. Suitable for machinery like pumps or electric motors where radial loads and secure mounting are key.
With a temperature range of -30°C to 120°C, it performs well in diverse environments. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.
"*" indicates required fields
How Does 6014NR/C3 Bearing Reduce Friction?
6014NR/C3 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
The snap ring groove design enhances stability, making it suitable for radial load applications.
With a dynamic radial load capacity of 8565 lbf, it handles demanding conditions effectively.
The open seal type allows for easy lubrication, maintaining performance over time.
Its temperature range of -30° to 120°C ensures reliability in various environments.
The C3 radial clearance provides optimal performance under different operating conditions.
Industrial Uses of 6014NR/C3 Bearing
6014NR/C3 Bearing is commonly used in industrial machinery, such as conveyor systems and pumps, where its snap ring groove ensures secure outer ring positioning. The C3 radial clearance allows for thermal expansion in demanding environments.
Where Is 6014NR/C3 Bearing Used?
You’ll find 6014NR/C3 Bearing in automotive applications like electric motors and gearboxes, where its chrome steel construction handles radial loads efficiently. Its metric sizing makes it a versatile choice for various vehicle designs.
Built for Heavy-Duty Use: 6014NR/C3 Bearing
6014NR/C3 Bearing excels in heavy machinery, such as agricultural equipment, thanks to its robust chrome steel rings and cage. The open design simplifies lubrication, extending service life in dusty or high-load conditions.
Automotive vs Industrial: Applications of 6014NR/C3 Bearing
In automotive settings, 6014NR/C3 Bearing supports wheel hubs and transmissions, while in industrial gear, it’s ideal for compressors and fans. The snap ring feature adds stability in high-vibration scenarios.
Perfect Fit for Automation: 6014NR/C3 Bearing
6014NR/C3 Bearing works well in robotic arms and automated assembly lines, where precision and reliability are key. Its ABEC 1 tolerance ensures consistent performance in repetitive motion applications.
