The SKF INSOCOAT NU 210 ECM/C3HVA3091 is a cylindrical roller bearing with a 50mm bore and 90mm outer diameter, featuring a durable insulation coating. It handles dynamic loads up to 73.5 kN and spins smoothly at speeds up to 8500 RPM.
Its VA3091 coating provides electrical insulation, preventing current damage, while the machined brass cage ensures reliable performance. The bearing operates safely with a breakdown voltage of 1000-3000 VDC.
With a C3H radial clearance, it accommodates thermal expansion in demanding conditions. Ideal for electric motors or generators where electrical insulation is crucial.
Weighing 0.551kg, it’s a robust yet compact solution. Compliant with RoHS and REACH standards for environmental safety.
"*" indicates required fields
How Is NU 210 ECM/C3HVA3091 Bearing Engineered for Reliability?
NU 210 ECM/C3HVA3091 Bearing features an insulating coating, protecting against electrical currents and extending its lifespan.
The machined brass cage ensures smooth operation, even at high speeds up to 8,500 rpm.
With a basic dynamic load rating of 73.5 kN, it handles heavy radial loads with ease.
The C3H radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
Its breakdown voltage ranges from 1,000 to 3,000 VDC, making it suitable for electrically demanding environments.
The coating provides a minimum electrical resistance of 50MΩ, preventing current passage and damage.
NU 210 ECM/C3HVA3091 Bearing’s robust design ensures durability in industrial applications.
Its compliance with ROHS and REACH standards highlights its environmental and safety credentials.
Industrial Uses of NU 210 ECM/C3HVA3091 Bearing
NU 210 ECM/C3HVA3091 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing. The machined brass cage ensures smooth operation even at high speeds.
Where Is NU 210 ECM/C3HVA3091 Bearing Used?
In automation systems, NU 210 ECM/C3HVA3091 Bearing supports robotic arms and conveyor belts, thanks to its high dynamic load rating. Its C3H clearance allows for thermal expansion in demanding environments.
Built for Heavy-Duty Use: NU 210 ECM/C3HVA3091 Bearing
NU 210 ECM/C3HVA3091 Bearing excels in industrial gearboxes, handling heavy radial loads with ease. The VA3091 coating provides reliable insulation, making it ideal for harsh electrical environments.
Automotive vs Aerospace: Applications of NU 210 ECM/C3HVA3091 Bearing
In automotive applications, NU 210 ECM/C3HVA3091 Bearing is found in alternators and starters, while in aerospace, it supports auxiliary power units. Its breakdown voltage rating ensures safety in critical systems.
Perfect Fit for Automation: NU 210 ECM/C3HVA3091 Bearing
NU 210 ECM/C3HVA3091 Bearing is a go-to choice for CNC machines and 3D printers, offering precision and durability. The brass cage reduces friction, enhancing performance in continuous operation.
