The SKF INSOCOAT cylindrical roller bearing is a medium-sized unit with a 110mm bore, 170mm outer diameter, and 28mm width, crafted from robust materials. It handles dynamic loads up to 390 kN and static loads up to 430 kN, suitable for demanding industrial environments.
Its outer ring features an insulating coating that protects against electrical currents, with a breakdown voltage ranging from 1000 to 3000 VDC. This helps prevent damage in electrically noisy settings, ensuring reliable operation.
With a machined brass cage and C3 radial clearance, it accommodates thermal expansion and maintains stability at high speeds up to 3600 RPM. The coating provides electrical resistance of at least 50 MΩ, reducing the risk of current-induced wear.
Ideal for use in electric motors, generators, or machinery where electrical insulation is needed, this bearing supports smooth performance in varied temperatures. It complies with RoHS and REACH standards, weighing 2.3 kg for easy handling in maintenance tasks.
"*" indicates required fields
How Does NU 1022 M/C3VL0241 Bearing Prevent Electrical Damage?
NU 1022 M/C3VL0241 Bearing features an insulating coating on its outer ring, protecting against electrical currents that can cause damage.
This coating provides breakdown voltage protection from 1000 to 3000 VDC, making it suitable for electric motor applications.
The machined brass cage maintains proper roller alignment, contributing to smooth operation under heavy loads.
With a basic dynamic load rating of 390 kN, NU 1022 M/C3VL0241 Bearing delivers reliable performance in demanding industrial environments.
How Does NU 1022 M/C3VL0241 Bearing Improve Performance?
NU 1022 M/C3VL0241 Bearing works well in industrial machinery like large pumps and conveyor systems where electrical currents could cause damage.
Its special insulation coating protects against electrical erosion, extending service life significantly.
You’ll find NU 1022 M/C3VL0241 Bearing in automotive electric motors and hybrid vehicle systems, handling radial loads efficiently.
The brass cage maintains stability at higher speeds, while the C3 clearance accommodates thermal expansion during operation.
For medical imaging equipment and laboratory devices, NU 1022 M/C3VL0241 Bearing offers reliable performance with its electrical insulation properties.
The consistent operation makes it suitable for precision instruments requiring minimal electrical interference.
In automation systems and robotic arms, NU 1022 M/C3VL0241 Bearing supports smooth rotational movement.
Its dimensional stability and load capacity make it practical for repetitive motion applications.
Around the home, NU 1022 M/C3VL0241 Bearing can be found in larger appliances like washing machines and power tools.
The insulation feature provides extra protection in motor-driven household equipment.
