The SKF INSOCOAT bearing 6330M/C4VL0241 is a robust unit measuring 150mm by 320mm by 65mm, featuring an insulating coating on the outer ring. It handles dynamic loads up to 286 kN and static loads up to 285 kN, with a reference speed of 4300 RPM.
The brass cage ensures smooth operation, while the C4 radial internal clearance provides flexibility in various conditions. The insulation coating offers protection against electrical currents, with a breakdown voltage of up to 3000V.
This bearing is ideal for electric motors or generators where electrical insulation is crucial. Its durable design and compliance with RoHS standards make it a reliable choice for industrial applications.
Weighing 25.4kg, it’s built to last in demanding environments. The coating also provides an electrical resistance of 200 MΩ, ensuring safe performance.
"*" indicates required fields
How Is 6330M/C4VL0241 Bearing Engineered for Reliability?
6330M/C4VL0241 Bearing features an insulation coating on the outer ring, preventing electrical damage in high-voltage environments.
The brass cage ensures smooth operation and reduces friction, enhancing overall performance.
With a basic dynamic load rating of 286.0 kN, it handles heavy loads efficiently.
Its reference speed of 4300.0 r/min makes it suitable for high-speed applications.
Industrial Uses of 6330M/C4VL0241 Bearing
The 6330M/C4VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing. Its brass cage ensures smooth operation even under high rotational speeds.
What Makes 6330M/C4VL0241 Bearing a Preferred Choice?
With a high dynamic load rating, 6330M/C4VL0241 Bearing handles heavy industrial loads effortlessly. The C4 radial clearance makes it suitable for applications with thermal expansion concerns.
Perfect Fit for Automation: 6330M/C4VL0241 Bearing
In robotic arms and automated machinery, 6330M/C4VL0241 Bearing offers reliable performance due to its stable electrical resistance. The 500 µm coating thickness provides consistent insulation over time.
Medical vs Industrial: Where 6330M/C4VL0241 Bearing Excels
While 6330M/C4VL0241 Bearing is ideal for industrial equipment like pumps, its precision also suits medical imaging devices. The breakdown voltage of ≤3000 V ensures safety in sensitive environments.
Key Fields for 6330M/C4VL0241 Bearing
Wind turbines benefit from 6330M/C4VL0241 Bearing’s ability to withstand variable loads and electrical isolation. The 65 mm width provides stability in large-scale applications.
