The SKF INSOCOAT bearing 6318M/C4VL0241 is a robust unit measuring 90mm by 190mm by 43mm, featuring an insulating coating on the outer ring. It handles dynamic loads up to 151 kN and static loads up to 108 kN, with a reference speed of 7500 RPM.
Its brass cage and C4 radial clearance ensure smooth operation, while the insulation coating prevents electrical arcing with a breakdown voltage of up to 3000V. The coating is 500µm thick and offers an electrical resistance of 200 MΩ.
This bearing is ideal for electric motors or generators where electrical insulation is crucial. Its durable design and compliance with RoHS standards make it a reliable choice for industrial applications.
Weighing 5.58kg, it balances strength and performance for demanding environments. The VL0241 coating suffix ensures easy identification for replacements or upgrades.
"*" indicates required fields
How Is 6318M/C4VL0241 Bearing Engineered for Reliability?
6318M/C4VL0241 Bearing features an insulating coating on the outer ring, providing protection against electrical currents.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 7,500 r/min.
With a basic dynamic load rating of 151 kN, it handles heavy loads while maintaining performance.
The C4 radial internal clearance allows for thermal expansion, making it suitable for various operating conditions.
Its breakdown voltage of ≤3000 V and electrical resistance of 200 MΩ enhance safety in electrical environments.
The 500 µm layer thickness ensures durability, reducing the risk of coating wear over time.
Industrial Uses of 6318M/C4VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage. The brass cage ensures smooth operation even under high-speed conditions.
Where Is 6318M/C4VL0241 Bearing Used?
You’ll find it in wind turbines and industrial pumps, handling heavy loads with ease. Its C4 clearance makes it suitable for applications with thermal expansion needs.
Built for Heavy-Duty Use: 6318M/C4VL0241 Bearing
Perfect for mining equipment, this bearing withstands harsh environments thanks to its robust design. The insulation coating adds an extra layer of protection against electrical currents.
Automotive vs Aerospace: Applications of 6318M/C4VL0241 Bearing
In automotive alternators, it ensures reliable performance, while in aerospace systems, its high-speed capability shines. The coating prevents electrical arcing in both scenarios.
Essential Roles of 6318M/C4VL0241 Bearing
From conveyor systems to compressors, this bearing delivers consistent performance. Its high dynamic load rating makes it a dependable choice for demanding industrial tasks.
