The SKF INSOCOAT bearing 6317M/C4VL0241 is a robust unit measuring 85mm by 180mm by 41mm, featuring an insulating coating on its outer ring. It handles dynamic loads up to 140 kN and static loads up to 96.5 kN, with a reference speed of 8000 RPM.
The brass cage and C4 radial clearance ensure smooth operation, while the 500µm insulation layer provides protection against electrical currents up to 3000V. Its electrical resistance of 200 MΩ makes it suitable for environments with electrical interference.
This bearing is ideal for electric motors or generators where insulation is crucial. Weighing 4.93kg, it’s a durable choice for industrial applications. Compliant with ROHS standards, it’s both safe and reliable.
The VL0241 coating suffix indicates its specialised insulation properties, making it a practical solution for preventing electrical damage in machinery.
"*" indicates required fields
How Is 6317M/C4VL0241 Bearing Engineered for Reliability?
6317M/C4VL0241 Bearing features an insulating coating on the outer ring, protecting against electrical currents and extending its lifespan.
The brass cage ensures smooth operation, even at high speeds up to 8,000 r/min.
With a basic dynamic load rating of 140 kN, it handles heavy loads reliably.
The C4 radial internal clearance allows for thermal expansion, making it suitable for varied operating conditions.
Industrial Uses of 6317M/C4VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents.
The brass cage ensures smooth operation even at high speeds, making it reliable for industrial applications.
Where Is 6317M/C4VL0241 Bearing Used?
You’ll often find this bearing in wind turbines and other renewable energy systems, thanks to its ability to handle high dynamic loads.
The C4 clearance allows for thermal expansion, which is essential in environments with fluctuating temperatures.
Perfect Fit for Automation: 6317M/C4VL0241 Bearing
In automated production lines, this bearing’s high reference speed keeps machinery running efficiently without overheating.
Its insulation coating also makes it a safe choice for equipment with variable frequency drives.
Automotive vs Aerospace: Applications of 6317M/C4VL0241 Bearing
While it’s not typically used in aerospace due to weight constraints, this bearing excels in heavy-duty automotive applications like large trucks.
The 180 mm outer diameter provides stability under heavy loads, ensuring long service life.
Medical vs Industrial: Where 6317M/C4VL0241 Bearing Excels
Though not common in medical devices, this bearing shines in industrial settings like pumps and compressors.
The 96.5 kN static load rating means it can handle sudden shocks without compromising performance.
