The SKF INSOCOAT bearing 6316M/C4VL0241 measures 80mm in bore diameter, 170mm outside, and 39mm wide, with a robust brass cage for durability. It handles dynamic loads up to 130kN and spins smoothly at speeds up to 8500 RPM.
Its outer ring features a 500µm insulation coating, providing electrical resistance of 200 MΩ and breakdown voltage up to 3000V. This makes it ideal for avoiding electrical currents in machinery.
With a C4 radial clearance, it accommodates thermal expansion in demanding conditions. The bearing is RoHS compliant, ensuring safe use in industrial applications.
Weighing 4.13kg, it’s a reliable choice for electric motors or generators where insulation is crucial. The design balances performance and protection against electrical damage.
"*" indicates required fields
How Is 6316M/C4VL0241 Bearing Engineered for Reliability?
6316M/C4VL0241 Bearing features an insulation coating on the outer ring, protecting against electrical currents.
Its brass cage ensures smooth operation and reduces friction, even at high speeds up to 8,500 r/min.
The bearing’s basic dynamic load rating of 130 kN makes it suitable for heavy-duty applications.
With a breakdown voltage of ≤3000 V, it offers reliable performance in electrically demanding environments.
Industrial Uses of 6316M/C4VL0241 Bearing
The 6316M/C4VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents.
Its brass cage and C4 clearance ensure smooth operation even under high thermal expansion conditions.
Where Is 6316M/C4VL0241 Bearing Used?
You’ll often find 6316M/C4VL0241 Bearing in wind turbines, where its high dynamic load rating handles the demanding rotational forces.
The insulation coating also makes it a reliable choice for industrial drives exposed to variable frequencies.
Ideal for Precision: 6316M/C4VL0241 Bearing
In CNC machinery, 6316M/C4VL0241 Bearing provides stable performance thanks to its consistent electrical resistance and breakdown voltage.
The 170mm outer diameter offers a sturdy fit for heavy spindle applications.
Automotive vs Aerospace: Applications of 6316M/C4VL0241 Bearing
While 6316M/C4VL0241 Bearing suits hybrid vehicle powertrains, its aerospace applications are limited due to weight constraints.
The coating’s 200 MΩ resistance makes it ideal for electric vehicle components prone to voltage fluctuations.
Practical Applications of 6316M/C4VL0241 Bearing
For industrial pumps, 6316M/C4VL0241 Bearing’s C4 clearance accommodates thermal expansion during continuous operation.
The 39mm width provides ample load distribution for high-pressure systems.
