The SKF 6315M/C4VL0241 is an INSOCOAT bearing with a 75mm bore and 160mm outer diameter, designed for electrical insulation. Its outer ring features a 500µm coating, providing up to 3000V breakdown voltage and 200MΩ resistance.
This bearing handles dynamic loads up to 119kN and spins smoothly at 9000 RPM, thanks to its brass cage and C4 radial clearance. The insulation prevents electrical arcing, making it ideal for electric motors or generators.
Weighing 3.56kg, it’s robust yet manageable for industrial use. Compliant with RoHS standards, it’s a reliable choice for applications where electrical isolation is crucial.
The VL0241 coating ensures long-term performance in environments with stray currents or frequent electrical discharges. Suitable for wind turbines or industrial machinery requiring insulated components.
"*" indicates required fields
How Is 6315M/C4VL0241 Bearing Engineered for Reliability?
6315M/C4VL0241 Bearing features an insulation coating on the outer ring, preventing electrical damage in high-voltage environments.
Its breakdown voltage of ≤3000 V ensures safe operation in electrically charged applications.
The brass cage design enhances durability and maintains ball alignment under high speeds.
With a reference speed of 9000 r/min, it delivers consistent performance in demanding conditions.
Basic dynamic load rating of 119 kN allows 6315M/C4VL0241 Bearing to handle heavy loads efficiently.
The C4 radial internal clearance ensures smooth operation even with thermal expansion.
6315M/C4VL0241 Bearing’s coating thickness of 500 µm provides robust insulation protection.
Its electrical resistance of 200 MΩ further safeguards against current leakage.
Industrial Uses of 6315M/C4VL0241 Bearing
6315M/C4VL0241 Bearing is commonly used in industrial motors and generators, where its insulating coating prevents electrical damage from stray currents. The brass cage ensures smooth operation even under high-speed conditions.
In wind turbine applications, 6315M/C4VL0241 Bearing handles variable loads efficiently, thanks to its C4 radial clearance. The high breakdown voltage makes it reliable in environments with electrical interference.
For railway traction motors, 6315M/C4VL0241 Bearing’s robust design and insulation properties reduce downtime. Its dynamic load rating of 119 kN ensures long service life in demanding conditions.
What Makes 6315M/C4VL0241 Bearing a Preferred Choice?
6315M/C4VL0241 Bearing is ideal for electric vehicle drivetrains, where insulation against high voltages is critical. The 500 µm coating thickness provides consistent protection over time.
In industrial pumps, 6315M/C4VL0241 Bearing’s resistance to electrical arcing extends component life. The 9000 r/min reference speed suits high-performance applications.
For HVAC systems, 6315M/C4VL0241 Bearing’s low-maintenance design reduces operational costs. The 200 MΩ electrical resistance ensures safety in moisture-prone environments.
Built for Heavy-Duty Use: 6315M/C4VL0241 Bearing
6315M/C4VL0241 Bearing excels in mining equipment, where dust and vibration demand durability. Its 76.5 kN static load rating handles shock loads effectively.
In marine applications, 6315M/C4VL0241 Bearing’s corrosion-resistant materials withstand harsh conditions. The brass cage prevents galling in saltwater environments.
For food processing machinery, 6315M/C4VL0241 Bearing’s RoHS compliance meets hygiene standards. The 37 mm width fits compact spaces without sacrificing performance.
Automotive vs Aerospace: Applications of 6315M/C4VL0241 Bearing
In automotive alternators, 6315M/C4VL0241 Bearing’s insulation protects against voltage spikes. The 160 mm OD accommodates space-constrained designs.
For aerospace actuators, 6315M/C4VL0241 Bearing’s lightweight 3.56 kg weight reduces fuel consumption. The C4 clearance compensates for thermal expansion at altitude.
In robotics, 6315M/C4VL0241 Bearing’s precision supports repetitive movements. The 75 mm bore size integrates seamlessly with servo motor shafts.
