The SKF INSOCOAT 6314M/C4VL0241 is a robust bearing with a 70mm bore and 150mm outer diameter, designed for electrical insulation. Its outer ring features a 500µm coating, providing up to 3000V breakdown voltage and 200MΩ resistance.
With a dynamic load rating of 104kN and a static load rating of 68kN, it handles heavy loads while maintaining smooth operation. The brass cage ensures durability, and the C4 radial clearance allows for thermal expansion.
This bearing is ideal for electric motors and generators where electrical insulation is crucial. It spins efficiently at speeds up to 9500 rpm, making it suitable for high-performance applications.
Weighing 2.92kg, it’s a sturdy choice for industrial use. Compliant with ROHS standards, it’s both reliable and environmentally friendly.
"*" indicates required fields
How Is 6314M/C4VL0241 Bearing Engineered for Reliability?
6314M/C4VL0241 Bearing features an insulating coating on the outer ring, preventing electrical damage in high-voltage environments.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 9,500 r/min.
With a basic dynamic load rating of 104.0 kN, it handles heavy loads reliably.
The C4 radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
Its breakdown voltage of ≤3000 V makes it suitable for electric motor applications.
The 500 µm layer thickness provides durable insulation, extending the bearing’s service life.
Industrial Uses of 6314M/C4VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical currents from causing damage. The brass cage ensures smooth operation even at high speeds.
Where Is 6314M/C4VL0241 Bearing Used?
You’ll find this bearing in wind turbines and industrial pumps, thanks to its ability to handle heavy loads and resist electrical arcing. Its C4 clearance makes it suitable for applications with thermal expansion.
Perfect Fit for Automation: 6314M/C4VL0241 Bearing
In robotic systems, 6314M/C4VL0241 Bearing provides reliable performance due to its high dynamic load rating. The insulation coating also protects against stray currents in automated environments.
Medical vs Industrial: Where 6314M/C4VL0241 Bearing Excels
While it’s not typically used in medical devices, 6314M/C4VL0241 Bearing shines in industrial settings like conveyor systems and compressors. Its durability and electrical insulation make it a versatile choice.
