The SKF INSOCOAT bearing 6234M/C4VL0241 is a robust unit measuring 170mm in bore diameter and 310mm outside, with a width of 52mm. It features an insulating coating on the outer ring, designed to handle electrical resistance up to 200 MΩ.
With a dynamic load rating of 225 kN and a static load rating of 224 kN, it performs well under heavy loads. Its reference speed reaches 3800 r/min, making it suitable for high-speed applications.
The brass cage ensures durability, while the C4 radial internal clearance allows for thermal expansion. The insulation coating prevents electrical arcing, ideal for electric motors or generators.
Weighing 18.096 kg, this bearing is RoHS compliant and built for demanding industrial environments where electrical insulation is crucial.
"*" indicates required fields
How Is 6234M/C4VL0241 Bearing Engineered for Reliability?
6234M/C4VL0241 Bearing features an insulating coating on the outer ring, preventing electrical damage in high-voltage environments.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 3800 r/min.
With a basic dynamic load rating of 225.0 kN, it handles heavy loads reliably.
Its C4 radial internal clearance allows for thermal expansion, making it suitable for varied operating conditions.
Industrial Uses of 6234M/C4VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents.
The brass cage ensures smooth operation even at high speeds, making it reliable for industrial applications.
Where Is 6234M/C4VL0241 Bearing Used?
You’ll often find this bearing in wind turbines, where its high dynamic load rating handles variable forces effectively.
The insulation coating also makes it suitable for frequency-driven motors, reducing the risk of electrical erosion.
Built for Heavy-Duty Use: 6234M/C4VL0241 Bearing
In mining equipment, this bearing’s C4 clearance accommodates thermal expansion under heavy loads.
Its robust design and insulation properties make it a go-to choice for harsh environments.
Automotive vs Aerospace: Applications of 6234M/C4VL0241 Bearing
While it’s used in automotive test rigs for its precision, the aerospace industry values its insulation for avionics cooling systems.
The high reference speed ensures performance in both sectors without compromising reliability.
Perfect Fit for Automation: 6234M/C4VL0241 Bearing
In robotic arms, this bearing’s low electrical resistance minimises interference with sensitive electronics.
The consistent breakdown voltage rating adds an extra layer of safety in automated systems.
