The SKF INSOCOAT bearing 6230/C3VL2071 is a robust unit measuring 150mm in bore diameter, 270mm outside, and 45mm wide, with a net weight of 9.82kg. Its inner ring features a 500µm insulating coating, providing electrical resistance up to 200 MΩ.
This bearing handles dynamic loads up to 186 kN and static loads of 166 kN, with a reference speed of 5000 RPM. The C3 radial clearance offers flexibility in high-temperature or high-speed applications.
The sheet metal cage ensures durability, while the VL2071 coating prevents electrical arcing, making it ideal for electric motors or generators. Compliant with ROHS standards, it’s a reliable choice for industrial machinery.
With a breakdown voltage of 3000V DC, it’s particularly suited for environments where electrical insulation is crucial. The combination of strength and insulation makes it versatile for various heavy-duty applications.
"*" indicates required fields
How Is 6230/C3VL2071 Bearing Engineered for Reliability?
6230/C3VL2071 Bearing features an inner ring insulation coating, providing protection against electrical currents.
With a breakdown voltage of up to 3000 V, it ensures safe operation in electrically demanding environments.
The C3 radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
Its dynamic load rating of 186.0 kN makes it suitable for heavy-duty applications.
Industrial Uses of 6230/C3VL2071 Bearing
The 6230/C3VL2071 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents. Its high dynamic load rating makes it suitable for heavy industrial equipment.
In wind turbine applications, 6230/C3VL2071 Bearing’s C3 clearance accommodates thermal expansion during continuous operation. The sheet metal cage provides durability in variable speed conditions.
For railway traction systems, this bearing’s VL2071 coating ensures reliable performance despite electrical interference. Its 500µm insulation layer offers long-term protection in demanding environments.
Where Is 6230/C3VL2071 Bearing Used?
You’ll find 6230/C3VL2071 Bearing in large industrial pumps handling corrosive fluids, where its insulation resists electrochemical corrosion. The 270mm outer diameter provides stable support for high-torque applications.
In metal processing equipment, 6230/C3VL2071 Bearing withstands both radial loads and electrical exposure. Its 186kN dynamic capacity ensures longevity in continuous production lines.
The bearing also works well in marine propulsion systems, where saltwater exposure demands robust electrical insulation. SKF’s quality control guarantees consistent performance in these challenging conditions.
Built for Heavy-Duty Use: 6230/C3VL2071 Bearing
6230/C3VL2071 Bearing handles the rigorous demands of mining equipment, with its 166kN static load rating supporting heavy machinery components. The 5000rpm reference speed suits various industrial gearboxes.
Its application in paper mill rollers demonstrates how the insulation coating prevents current-induced pitting. The 45mm width provides optimal load distribution for these continuous operation systems.
For food processing conveyors, the bearing’s ROHS compliance ensures safety in hygienic environments. The C3 clearance accommodates thermal changes during frequent washdown procedures.
