The SKF INSOCOAT bearing 6224M/C3VL0241 measures 120mm in bore diameter and 215mm outside, with a 40mm width. Its outer ring features a 500µm insulation coating to prevent electrical damage.
With a dynamic load rating of 146kN and static load capacity of 118kN, it handles heavy loads smoothly. The brass cage ensures durability, while the C3 clearance allows for thermal expansion.
The insulation coating provides up to 3000V protection, ideal for electric motors or generators. It spins up to 6300 RPM, making it suitable for high-speed applications.
Weighing 6.4kg, this RoHS-compliant bearing offers reliable performance in environments where electrical currents could cause damage. Its 200 MΩ resistance ensures long-term insulation effectiveness.
"*" indicates required fields
How Is 6224M/C3VL0241 Bearing Engineered for Reliability?
6224M/C3VL0241 Bearing features an insulation coating on the outer ring, protecting against electrical currents and extending its lifespan.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 6,300 r/min.
With a basic dynamic load rating of 146 kN, it handles heavy loads reliably in demanding applications.
Its C3 radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
What Makes 6224M/C3VL0241 Bearing Suitable for High-Temperature Applications?
6224M/C3VL0241 Bearing’s insulation coating withstands high temperatures, ensuring consistent performance in harsh environments.
The brass cage material enhances durability, reducing wear even under continuous operation.
Its breakdown voltage of up to 3,000 V prevents damage from electrical currents, improving reliability.
With a layer thickness of 500 µm, the coating provides robust protection against electrical arcing.
Designed for Durability: 6224M/C3VL0241 Bearing
6224M/C3VL0241 Bearing’s insulation coating offers excellent electrical resistance, measured at 200 MΩ.
The C3 radial clearance accommodates thermal expansion, ensuring stable operation under load.
Its high dynamic load rating of 146 kN makes it suitable for heavy-duty industrial applications.
The brass cage maintains ball alignment, reducing friction and extending service life.
Steel vs Ceramic Bearings: Strengths of 6224M/C3VL0241 Bearing
6224M/C3VL0241 Bearing combines chrome steel construction with an insulating coating for superior reliability.
The brass cage ensures smooth rotation, even at speeds up to 6,300 r/min.
Its electrical resistance of 200 MΩ prevents current damage, making it ideal for electric motors.
With a static load rating of 118 kN, it delivers strong performance in stationary applications.
Industrial Uses of 6224M/C3VL0241 Bearing
The 6224M/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing. This makes it a reliable choice for industries dealing with high-voltage equipment.
In automotive applications, 6224M/C3VL0241 Bearing can be found in hybrid and electric vehicle drivetrains. Its brass cage and C3 clearance ensure smooth performance under varying loads and temperatures.
For automation systems, 6224M/C3VL0241 Bearing supports robotic arms and conveyor belts, where precision and durability are key. The insulation coating also reduces downtime caused by electrical damage.
In wind turbines, 6224M/C3VL0241 Bearing handles high dynamic loads while maintaining electrical insulation. Its robust design makes it suitable for harsh environmental conditions.
The 6224M/C3VL0241 Bearing is also used in medical imaging devices, where consistent rotation and electrical safety are critical. The coating ensures reliable operation in sensitive diagnostic equipment.
