Single Row Deep Groove Ball Bearings With Filling Slots 306/C3
Single Row Deep Groove Ball Bearings With Filling Slots 306/C3

Single Row Deep Groove Ball Bearings With Filling Slots 306/C3

The 306/C3 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6677 lbf and spins smoothly at speeds up to 11000 RPM.

Its open design with filling slots allows easy lubrication, while the chrome steel cage ensures durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.37kg, it offers a balance of strength and lightweight design. Compliant with REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 306/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 6677 lbf
  • Static Radial Load 4856 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.37 kg
  • Price($) 10.53

Features

Performance Features of 306/C3 Bearing

306/C3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 6677 lbf, making it suitable for demanding applications.

The single-row deep groove design ensures smooth operation and efficient load distribution.
With a maximum speed of 11,000 rpm, it balances performance and durability.

306/C3 Bearing operates in temperatures from -30°C to 120°C, adapting to various environments.
Its C3 radial clearance provides flexibility in different operating conditions.

Application

Industrial Uses of 306/C3 Bearing
306/C3 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 306/C3 Bearing fits well in wheel hubs and transmission systems, providing smooth rotation under varying speeds. Its C3 clearance ensures reliable performance even with thermal expansion in engine compartments.

For automation equipment, 306/C3 Bearing’s chrome steel construction offers durability in robotic arms and conveyor belts. The metric sizing makes it a versatile choice for European and Asian machinery standards.

Where Is 306/C3 Bearing Used?
You’ll find 306/C3 Bearing in household appliances like washing machines, where its quiet operation and load capacity are ideal. The chrome steel balls reduce friction, ensuring long-term reliability.

In agricultural machinery, 306/C3 Bearing supports components like gearboxes and harvesters, handling heavy radial loads with ease. Its wide temperature range makes it suitable for outdoor use in various climates.
