The 209-Z is a single-row deep groove ball bearing with a 45mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 7913 lbf and operates smoothly at speeds up to 8500 RPM.
Its shielded design keeps dirt out while the nylon cage reduces friction for quieter performance. The bearing works in temperatures from -30°C to 120°C and comes pre-lubricated with grease for easy use.
This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for electric motors or pumps where reliable radial load handling is needed.
Weighing 0.44kg, it balances durability with manageable size. Compliant with RoHS and REACH standards for safe industrial applications.
"*" indicates required fields
Why Choose 209-Z Bearing for Precision Tasks?
209-Z Bearing features a single row deep groove design with filling slots, ideal for precise radial load applications.
Its chrome steel rings and balls provide reliable strength, supporting dynamic radial loads up to 7913 lbf.
The shielded design and nylon cage reduce friction, ensuring smooth operation at speeds up to 8,500 rpm.
With a temperature range of -30° to 120°C, it performs well in various environments.
Grease lubrication enhances durability, making 209-Z Bearing a practical choice for long-term use.
Its compact size (45 mm×85 mm×19 mm) allows for easy integration into different machinery setups.
Industrial Uses of 209-Z Bearing
209-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The nylon cage reduces friction, making it suitable for continuous operation.
In automotive applications, 209-Z Bearing fits well in components such as alternators and water pumps, thanks to its radial load capacity. The grease lubrication ensures smooth performance even under varying temperatures.
For automation systems, 209-Z Bearing works reliably in robotic arms and conveyor belts, where precision and durability are key. Its metric sizing makes it easy to integrate into various European and Asian equipment designs.
Around the home, 209-Z Bearing can be found in appliances like washing machines, where its sturdy construction handles daily wear. The chrome steel rings provide long-lasting performance in these high-use scenarios.
