Single Row Deep Groove Ball Bearings 6311 Y/C782
Single Row Deep Groove Ball Bearings 6311 Y/C782

Single Row Deep Groove Ball Bearings 6311 Y/C782

The 6311 Y/C782 is a single-row deep groove ball bearing with a 55mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 16096 lbf and operates smoothly at speeds up to 5600 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are typical.

Weighing 1350g, it balances strength and practicality. Compliant with RoHS and REACH standards for safe usage.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6311 Y/C782
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 29 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 16096 lbf
  • Static Radial Load 10116 lbf
  • Max Speed 5600 rpm
  • Weight 1350 g
  • price($) 112.068

Features

Performance Features of 6311 Y/C782 Bearing

6311 Y/C782 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 16096 lbf.
Its single-row deep groove design ensures smooth operation and efficient load distribution.
The open seal type allows for easy maintenance and lubrication adjustments.
With a maximum speed of 5,600 rpm, it performs reliably in various industrial applications.

Application

Common Applications of 6311 Y/C782 Bearing
This bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 6311 Y/C782 Bearing supports components like alternators and water pumps, providing smooth rotation under varying loads. Its chrome steel construction offers durability, making it suitable for long-term use in vehicles.

For automation systems, 6311 Y/C782 Bearing is a solid choice for robotic arms and conveyor belts, where precision and stability are key. The ABEC 1 tolerance ensures consistent performance in high-speed operations.

In household appliances like washing machines, 6311 Y/C782 Bearing handles radial loads efficiently, contributing to quiet and smooth operation. Its temperature range makes it adaptable to different environmental conditions.
