Single Row Deep Groove Ball Bearings 6306 TN9/C4VC486
Single Row Deep Groove Ball Bearings 6306 TN9/C4VC486

Single Row Deep Groove Ball Bearings 6306 TN9/C4VC486

The 6306 TN9/C4VC486 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6002 lbf and spins smoothly at speeds up to 9600 RPM.

Its open design and nylon cage reduce friction, ensuring quiet operation and easy maintenance. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 346g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6306 TN9/C4VC486
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6002 lbf
  • Static Radial Load 3372 lbf
  • Max Speed 9600 rpm
  • Weight 346 g

Features

Why Choose 6306 TN9/C4VC486 Bearing for Precision Tasks?

6306 TN9/C4VC486 Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its chrome steel rings and balls ensure durability, while the nylon cage reduces friction for smoother operation.
With a dynamic radial load capacity of 6002 lbf, it performs reliably in various applications.
The bearing operates efficiently at speeds up to 9,600 rpm and withstands temperatures from -30° to 120°C.

Application

Common Applications of 6306 TN9/C4VC486 Bearing
In industrial settings, 6306 TN9/C4VC486 Bearing is widely used in machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type simplifies lubrication, making it suitable for high-speed operations.

Where Is 6306 TN9/C4VC486 Bearing Used?
You’ll often find 6306 TN9/C4VC486 Bearing in automotive applications, such as wheel hubs and alternators, thanks to its durable chrome steel construction. Its C4 clearance ensures reliable performance even under varying thermal conditions.

Ideal for Precision: 6306 TN9/C4VC486 Bearing
For medical devices like centrifuges, 6306 TN9/C4VC486 Bearing offers smooth rotation and low noise, essential for sensitive environments. The nylon cage reduces friction, enhancing its lifespan in continuous-use scenarios.

Automotive vs Industrial: Applications of 6306 TN9/C4VC486 Bearing
In automotive systems, 6306 TN9/C4VC486 Bearing supports components like transmissions, while in industrial gearboxes, it handles heavy radial loads. Its versatility makes it a go-to choice across different sectors.

Practical Applications of 6306 TN9/C4VC486 Bearing
For household appliances like washing machines, 6306 TN9/C4VC486 Bearing ensures quiet and efficient operation. The metric dimensions make it easy to integrate into various European and Asian appliance designs.
