Single Row Deep Groove Ball Bearings 6305 TN9/C3
Single Row Deep Groove Ball Bearings 6305 TN9/C3

Single Row Deep Groove Ball Bearings 6305 TN9/C3

The 6305 TN9/C3 is a single-row deep groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4631 lbf and reaches speeds of 11000 RPM smoothly.

Its open design and nylon cage reduce friction, making it efficient for various applications. The bearing operates reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. It’s well-suited for electric motors, pumps, or machinery requiring consistent radial load support.

Weighing 232g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, ensuring safety and environmental friendliness.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6305 TN9/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4631 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 232 g
  • price($) 5.616

Features

Performance Features of 6305 TN9/C3 Bearing

6305 TN9/C3 Bearing is built with chrome steel rings and balls, offering strong radial load support.
Its dynamic radial load capacity reaches 4631 lbf, making it suitable for various industrial uses.

The nylon cage in 6305 TN9/C3 Bearing helps reduce friction and noise during operation.
This design ensures smooth performance even at high speeds up to 11,000 rpm.

6305 TN9/C3 Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its open design allows for easy maintenance and lubrication adjustments when needed.

With a C3 radial clearance, 6305 TN9/C3 Bearing accommodates thermal expansion in demanding conditions.
The precise tolerances ensure reliable performance in radial load applications.

Application

Common Applications of 6305 TN9/C3 Bearing
The 6305 TN9/C3 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design and nylon cage make it suitable for moderate-speed operations.

In automotive applications, 6305 TN9/C3 Bearing can be found in alternators and wheel hubs, providing smooth rotation under radial loads. The C3 clearance allows for thermal expansion, making it adaptable to varying temperatures.

For automation systems, 6305 TN9/C3 Bearing supports robotic arms and conveyor belts, where its durability and ease of maintenance are key advantages. The chrome steel construction ensures long service life even in demanding conditions.

In household appliances like washing machines, 6305 TN9/C3 Bearing offers quiet and efficient operation. Its metric sizing and compatibility with various brands make it a versatile choice for replacements.
