The 627-2RZTN9/HC5C3LTF2 is a compact single-row deep groove ball bearing, measuring 7mm in bore and 22mm in outer diameter, with a width of just 7mm. Made from chrome steel and featuring silicon nitride balls, it offers a good balance of strength and smooth operation.
This sealed bearing handles radial loads up to 629 lbf and can spin at speeds up to 30,000 RPM. Its nylon cage reduces friction, while the C3 radial clearance allows for slight misalignment.
The sealed design keeps contaminants out, making it low-maintenance. It performs well in temperatures from -30°C to 120°C, suitable for various environments.
Ideal for small machinery, electric motors, or appliances where reliable radial load support is needed. Compliant with RoHS and REACH standards, it’s a safe and versatile choice. Weighing only 12.7g, it’s lightweight yet durable.
"*" indicates required fields
Performance Features of 627-2RZTN9/HC5C3LTF2 Bearing
627-2RZTN9/HC5C3LTF2 Bearing is built with chrome steel rings and silicon nitride balls, offering excellent radial load capacity.
Its dynamic radial load reaches 629 lbf, making it suitable for various applications.
The sealed design of 627-2RZTN9/HC5C3LTF2 Bearing protects against dust and moisture, ensuring long-term reliability.
Nylon cage material reduces friction and noise, enhancing smooth operation.
With a maximum speed of 30,000 rpm, 627-2RZTN9/HC5C3LTF2 Bearing delivers efficient performance.
Its temperature range of -30°C to 120°C allows for use in diverse environments.
627-2RZTN9/HC5C3LTF2 Bearing’s compact size of 7 mm×22 mm×7 mm makes it ideal for space-constrained applications.
The ABEC 1 tolerance ensures consistent precision in operation.
Common Applications of 627-2RZTN9/HC5C3LTF2 Bearing
In small electric motors, 627-2RZTN9/HC5C3LTF2 Bearing offers smooth rotation thanks to its sealed design and silicon nitride balls. The compact size makes it ideal for tight spaces where reliability is key.
Where Is 627-2RZTN9/HC5C3LTF2 Bearing Used?
You’ll often spot 627-2RZTN9/HC5C3LTF2 Bearing in household appliances like fans or power tools, where its nylon cage reduces noise. Its C3 clearance ensures it handles slight misalignments without fuss.
Built for Versatility: 627-2RZTN9/HC5C3LTF2 Bearing
From office printers to light-duty conveyor systems, 627-2RZTN9/HC5C3LTF2 Bearing delivers consistent performance. The chrome steel rings provide durability, while the temperature range suits most indoor environments.
Light-Duty vs Heavy-Duty: Best Uses for 627-2RZTN9/HC5C3LTF2 Bearing
For light loads in robotics or medical devices, 627-2RZTN9/HC5C3LTF2 Bearing’s precision shines. It’s less suited for heavy machinery but excels in applications needing quiet, low-friction operation.
