Single Row Deep Groove Ball Bearings 62201-2RS1/W64
Single Row Deep Groove Ball Bearings 62201-2RS1/W64

Single Row Deep Groove Ball Bearings 62201-2RS1/W64

The 62201-2RS1/W64 is a compact single-row deep groove ball bearing, measuring 12mm by 32mm by 14mm, crafted from durable chrome steel. It handles radial loads up to 1549 lbf and spins smoothly at speeds up to 15,000 RPM.

Its sealed design keeps lubrication in and contaminants out, while the solid oil lubrication ensures long-lasting performance. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 0.045kg, it’s lightweight yet sturdy for its size. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 62201-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 14 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1549 lbf
  • Static Radial Load 697 lbf
  • Max Speed 15000 rpm
  • Weight 0.045 kg

Features

Performance Features of 62201-2RS1/W64 Bearing

62201-2RS1/W64 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1549 lbf, ensuring reliable performance in various applications.

The sealed design and solid oil lubrication reduce maintenance needs while extending service life.
With a maximum speed of 15,000 rpm, it balances efficiency and durability for smooth operation.

62201-2RS1/W64 Bearing works in temperatures from -30°C to 120°C, making it suitable for diverse environments.
Its compact size (12 mm × 32 mm × 14 mm) allows for easy integration into different systems.

Application

Common Applications of 62201-2RS1/W64 Bearing
In industrial settings, 62201-2RS1/W64 Bearing is commonly used in conveyor systems and small electric motors, where its sealed design keeps contaminants out. The solid oil lubrication ensures long service life even in dusty environments.

Where Is 62201-2RS1/W64 Bearing Used?
You’ll often find 62201-2RS1/W64 Bearing in automotive applications like alternators and small gearboxes, thanks to its reliable radial load handling. Its compact size makes it ideal for tight spaces in vehicle assemblies.

Ideal for Precision: 62201-2RS1/W64 Bearing
For medical devices like dental drills or lab equipment, 62201-2RS1/W64 Bearing offers smooth, quiet operation. The chrome steel construction provides durability while maintaining precision in sensitive applications.

Automotive vs Industrial: Applications of 62201-2RS1/W64 Bearing
In cars, 62201-2RS1/W64 Bearing works well in cooling fans and pumps, while in factories, it’s suited for small machinery requiring consistent performance. The wide temperature range allows for versatility across different environments.

Practical Applications of 62201-2RS1/W64 Bearing
Home appliances like washing machines and power tools benefit from 62201-2RS1/W64 Bearing’s sealed design, which reduces maintenance needs. Its ABEC 1 tolerance ensures reliable performance for everyday use.
