Single Row Deep Groove Ball Bearings 6212 M
Single Row Deep Groove Ball Bearings 6212 M

Single Row Deep Groove Ball Bearings 6212 M

The 6212 M is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 12432 lbf and operates smoothly at speeds reaching 11000 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical option for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.93kg, it balances strength and portability. Compliant with RoHS and REACH standards for safe usage.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6212 M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 22 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 12432 lbf
  • Static Radial Load 8093 lbf
  • Max Speed 11000 rpm
  • Weight 0.93 kg

Features

Performance Features of 6212 M Bearing

6212 M Bearing is built with chrome steel rings and balls, offering excellent resistance to radial loads.
Its dynamic radial load capacity reaches 12432 lbf, making it suitable for demanding industrial applications.

The stainless steel cage ensures proper ball alignment, reducing friction and enhancing durability.
With a maximum speed of 11,000 rpm, it delivers reliable performance in high-speed operations.

6212 M Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its open design allows for easy lubrication, ensuring smooth and consistent performance over time.

Application

Industrial Uses of 6212 M Bearing
6212 M Bearing is commonly used in industrial machinery like pumps and electric motors, where its single-row design handles radial loads efficiently. The open seal type allows for easy lubrication, extending service life in demanding conditions.

What Makes 6212 M Bearing a Preferred Choice?
In automotive applications, 6212 M Bearing fits well in wheel hubs and alternators, thanks to its balanced load capacity and smooth operation. The P6 tolerance class ensures precision, making it reliable for high-performance vehicles.

Perfect Fit for Automation: 6212 M Bearing
For automated systems, 6212 M Bearing’s stainless steel cage reduces friction in robotic arms and conveyor belts. Its metric sizing simplifies integration with European and Asian machinery standards.

Medical vs Industrial: Where 6212 M Bearing Excels
In medical devices like centrifuges, 6212 M Bearing’s chrome steel construction offers durability and quiet operation. Meanwhile, its industrial-grade performance shines in heavy machinery like compressors and gearboxes.

Light-Duty vs Heavy-Duty: Best Uses for 6212 M Bearing
For light-duty tasks, 6212 M Bearing works well in household appliances like washing machines. In heavy-duty settings, it supports radial loads in construction equipment, proving its versatility.
