Single Row Deep Groove Ball Bearings 6211-2RS1/C3WT
Single Row Deep Groove Ball Bearings 6211-2RS1/C3WT

Single Row Deep Groove Ball Bearings 6211-2RS1/C3WT

The 6211-2RS1/C3WT is a sealed single row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 9757 lbf and operates smoothly at speeds up to 6300 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The C3 radial clearance allows for slight expansion under heat, ensuring reliable performance.

This bearing is interchangeable with SKF models, offering a cost-effective alternative. It works well in temperatures from -30°C to 120°C, suitable for motors or pumps.

Weighing 599g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for various industrial applications.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6211-2RS1/C3WT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 9757 lbf
  • Static Radial Load 6609 lbf
  • Max Speed 6300 rpm
  • Weight 599 g

Features

Performance Features of 6211-2RS1/C3WT Bearing

6211-2RS1/C3WT Bearing is built with chrome steel rings and balls, offering strong radial load support.
Its dynamic radial load capacity reaches 9757 lbf, making it suitable for various industrial applications.

The sealed design of 6211-2RS1/C3WT Bearing protects against dust and moisture, enhancing durability.
With a maximum speed of 6,300 rpm, it ensures smooth operation in demanding conditions.

6211-2RS1/C3WT Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its C3 radial clearance provides flexibility for thermal expansion in different environments.

Application

Industrial Uses of 6211-2RS1/C3WT Bearing
The 6211-2RS1/C3WT Bearing is commonly used in industrial machinery, such as conveyor systems and electric motors, where its sealed design helps keep out dust and debris. Its chrome steel construction ensures durability in demanding environments.

What Makes 6211-2RS1/C3WT Bearing a Preferred Choice?
In automotive applications, 6211-2RS1/C3WT Bearing is often found in wheel hubs and transmissions, providing reliable performance under radial loads. The C3 clearance allows for better thermal expansion handling in high-speed scenarios.

Perfect Fit for Automation: 6211-2RS1/C3WT Bearing
For robotic arms and automated production lines, 6211-2RS1/C3WT Bearing offers smooth operation and low maintenance due to its sealed design. The metric sizing ensures compatibility with a wide range of equipment.

Light-Duty vs Heavy-Duty: Best Uses for 6211-2RS1/C3WT Bearing
In light-duty applications like household appliances, 6211-2RS1/C3WT Bearing provides quiet and efficient performance. For heavier tasks, such as agricultural machinery, its robust construction handles radial loads with ease.
