The 6206-2Z/C3GWP is a single row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4384 lbf and can spin at speeds up to 11000 RPM.
Shielded on both sides, it keeps dirt out while maintaining smooth operation. The C3 radial clearance allows for slight thermal expansion, making it versatile in varying temperatures.
This bearing is interchangeable with SKF models, offering a cost-effective alternative. Ideal for electric motors or pumps where reliable radial load support is needed.
Weighing 199g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it operates safely between -30°C and 120°C.
"*" indicates required fields
Performance Features of 6206-2Z/C3GWP Bearing
6206-2Z/C3GWP Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4384 lbf.
Its shielded design protects against contaminants, ensuring smooth operation in various environments.
The C3 radial clearance allows for thermal expansion, making it suitable for higher temperature applications.
With a maximum speed of 11,000 rpm, it delivers reliable performance for industrial use.
Common Applications of 6206-2Z/C3GWP Bearing
You’ll often spot 6206-2Z/C3GWP Bearing in industrial gear like electric motors and pumps, where its shielded design keeps contaminants out while handling radial loads smoothly.
In automotive applications, this bearing works well in alternators and wheel hubs, thanks to its C3 clearance allowing for thermal expansion during long drives.
For home appliances, 6206-2Z/C3GWP Bearing keeps things quiet in washing machines and fans, with chrome steel construction that withstands daily use without fuss.
The metric sizing makes it a straightforward replacement in European machinery, while the wide temperature range suits everything from factory floors to sunny outdoor equipment.
