The 6204/VW514 is a single-row deep groove ball bearing with a 20mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2878 lbf and spins smoothly at speeds up to 15,000 RPM.
Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates well in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.
Weighing just 106g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of 6204/VW514 Bearing
6204/VW514 Bearing is built with chrome steel rings and balls, offering strong radial load support.
Its dynamic radial load capacity reaches 2878 lbf, making it suitable for various applications.
The open design allows for easy lubrication, ensuring smooth operation.
With a maximum speed of 15,000 rpm, it delivers reliable performance in demanding conditions.
How Does 6204/VW514 Bearing Reduce Friction?
6204/VW514 Bearing features a single row deep groove design, minimising friction during operation.
The chrome steel construction ensures durability and reduces wear over time.
Its ABEC 1 tolerance class provides consistent performance for general applications.
The open seal type allows for easy maintenance and lubrication.
Designed for Durability: 6204/VW514 Bearing
6204/VW514 Bearing’s chrome steel cage keeps the balls aligned, enhancing longevity.
It operates efficiently within a temperature range of -30°C to 120°C.
The bearing’s static radial load capacity of 1495 lbf ensures stability under pressure.
Its compact size of 20 mm×47 mm×14 mm makes it versatile for various uses.
Steel vs Ceramic Bearings: Strengths of 6204/VW514 Bearing
6204/VW514 Bearing uses chrome steel for all components, balancing cost and performance.
This material choice provides good resistance to wear and tear.
The bearing’s radial clearance trade number CN ensures smooth operation.
It complies with RoHS and REACH standards, making it environmentally friendly.
Common Applications of 6204/VW514 Bearing
The 6204/VW514 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. Its open design allows for easy lubrication and maintenance, making it a reliable choice for various settings.
In automotive applications, 6204/VW514 Bearing fits well in components like alternators and wheel hubs, thanks to its durable chrome steel construction. The metric sizing ensures compatibility with a broad range of vehicle models, both domestic and international.
For household appliances, 6204/VW514 Bearing is often found in washing machines and fans, where its quiet performance and longevity are appreciated. The ABEC 1 tolerance class provides sufficient precision for everyday use without unnecessary cost.
Automation systems benefit from 6204/VW514 Bearing in robotic arms and conveyor belts, where consistent performance is key. Its ability to handle moderate speeds and loads makes it a versatile option for light to medium-duty tasks.
