Single Row Deep Groove Ball Bearings 6201-2RS
Single Row Deep Groove Ball Bearings 6201-2RS

Single Row Deep Groove Ball Bearings 6201-2RS

The 6201-2RS is a compact single-row deep groove ball bearing with a 12mm bore and 32mm outer diameter, crafted from durable chrome steel. Its sealed design keeps out dust and dirt, making it low-maintenance.

This bearing handles radial loads up to 1529 lbf and can spin at speeds up to 22000 RPM, suitable for various applications. The chrome steel cage adds strength and longevity.

With a temperature range of -30°C to 120°C, it works well in diverse environments. It’s also interchangeable with SKF bearings for easy replacement.

Ideal for small motors, pumps, or appliances where reliable performance is needed. Compliant with RoHS and REACH standards, it’s a safe and practical choice. Weighing just 37g, it’s lightweight yet robust.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6201-2RS
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 10 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1529 lbf
  • Static Radial Load 686 lbf
  • Max Speed 22000 rpm
  • Weight 37 g
  • price($) 2.322

Features

Performance Features of 6201-2RS Bearing

6201-2RS Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1529 lbf, making it suitable for various applications.
The sealed design protects against dust and moisture, ensuring smooth operation.
With a maximum speed of 22,000 rpm, it delivers reliable performance in demanding conditions.

Application

Common Applications of 6201-2RS Bearing
In industrial machinery, 6201-2RS Bearing is a reliable choice for radial load support, often used in pumps and small motors. Its sealed design helps keep contaminants out, extending service life in dusty environments.

Where Is 6201-2RS Bearing Used?
You’ll find 6201-2RS Bearing in automotive applications like alternators and cooling fans, where its compact size and durability are key. The chrome steel construction ensures it handles everyday wear without issues.

Built for Versatility: 6201-2RS Bearing
This bearing works well in household appliances, such as washing machines and power tools, thanks to its balanced performance. The ABEC 1 tolerance makes it suitable for general-purpose use where precision isn’t critical.

Automotive vs Industrial: Applications of 6201-2RS Bearing
In cars, 6201-2RS Bearing supports smooth rotation in auxiliary systems, while in factories, it’s often part of conveyor rollers. The metric sizing ensures easy replacement across different equipment types.

Perfect Fit for Automation: 6201-2RS Bearing
For small robotics or 3D printers, 6201-2RS Bearing offers quiet operation and decent load capacity. Its sealed design reduces maintenance needs, making it ideal for continuous-use setups.
