Single Row Deep Groove Ball Bearings 6014-2Z/C3 GJN
Single Row Deep Groove Ball Bearings 6014-2Z/C3 GJN

Single Row Deep Groove Ball Bearings 6014-2Z/C3 GJN

The 6014-2Z/C3 GJN is a single-row deep groove ball bearing with a 70mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 8565 lbf and runs smoothly at speeds up to 6000 RPM.

Shielded on both sides, it keeps dirt out while maintaining smooth operation. The C3 radial clearance allows for slight thermal expansion, making it versatile for various conditions.

This bearing works well in temperatures from -30°C to 120°C, suitable for industrial machinery or electric motors. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 598g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and durable choice for everyday applications.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6014-2Z/C3 GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 8565 lbf
  • Static Radial Load 6947 lbf
  • Max Speed 6000 rpm
  • Weight 598 g
  • price($) 18.36

Features

Performance Features of 6014-2Z/C3 GJN Bearing

6014-2Z/C3 GJN Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 8565 lbf, making it suitable for various industrial applications.

The shielded design protects against dust and debris, ensuring smooth operation.
With a maximum speed of 6,000 rpm, it balances performance and durability.

The C3 radial clearance allows for thermal expansion, making it reliable in varying temperatures.
Its ABEC 1 tolerance ensures consistent performance without unnecessary precision costs.

Application

Industrial Uses of 6014-2Z/C3 GJN Bearing
This bearing is commonly used in conveyor systems and industrial fans, where its shielded design helps keep contaminants out. The C3 clearance ensures reliable performance even with thermal expansion in heavy machinery.

What Makes 6014-2Z/C3 GJN Bearing a Preferred Choice?
In automotive applications like electric motors, 6014-2Z/C3 GJN Bearing handles radial loads smoothly. Its chrome steel construction offers durability, making it suitable for long-term use in demanding conditions.

Perfect Fit for Automation: 6014-2Z/C3 GJN Bearing
You’ll often find this bearing in robotic arms and assembly line equipment. The shielded seals protect against dust, while the ABEC 1 tolerance ensures consistent precision.

Medical vs Industrial: Where 6014-2Z/C3 GJN Bearing Excels
While it’s not typically used in medical devices, 6014-2Z/C3 GJN Bearing shines in industrial pumps and compressors. Its wide temperature range allows it to perform reliably in various environments.

Practical Applications of 6014-2Z/C3 GJN Bearing
For household appliances like washing machines, this bearing provides quiet and efficient operation. The metric sizing makes it easy to replace in European and Asian models.
