Single Row Deep Groove Ball Bearings 312SFFC
Single Row Deep Groove Ball Bearings 312SFFC

Single Row Deep Groove Ball Bearings 312SFFC

The 312SFFC is a single-row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 20525 lbf and operates smoothly at speeds up to 6000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are predominant.

Weighing 1.85kg, it balances strength and size effectively. Compliant with RoHS and REACH standards for safe usage.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 312SFFC
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 20525 lbf
  • Static Radial Load 17535 lbf
  • Max Speed 6000 rpm
  • Weight 1.85 kg
  • price($) 88.578

Features

Performance Features of 312SFFC Bearing

312SFFC Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.

Its dynamic radial load capacity reaches 20525 lbf, ensuring reliable performance in various applications.

The chrome steel cage maintains ball alignment, reducing friction and extending service life.

With a maximum speed of 6,000 rpm, it balances durability and efficiency for smooth operation.

Application

Industrial Uses of 312SFFC Bearing
312SFFC Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

Where Is 312SFFC Bearing Used?
You’ll often find 312SFFC Bearing in automotive applications such as wheel hubs and alternators, thanks to its durable chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: 312SFFC Bearing
In automation systems, 312SFFC Bearing supports robotic arms and conveyor belts, handling radial loads with ease. The ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

Medical vs Industrial: Where 312SFFC Bearing Excels
While 312SFFC Bearing performs well in industrial gearboxes, it’s also suitable for medical devices like centrifuges. The chrome steel balls and cage provide smooth operation and resistance to wear.

Perfect Fit for Automation: 312SFFC Bearing
312SFFC Bearing is ideal for 3D printers and CNC machines, where its radial load handling and speed capabilities are crucial. The open seal design simplifies maintenance, reducing downtime.
