Single Row Deep Groove Ball Bearings 307SFFG
Single Row Deep Groove Ball Bearings 307SFFG

Single Row Deep Groove Ball Bearings 307SFFG

The 307SFFG is a single row deep groove ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 7801 lbf and operates smoothly at speeds up to 9500 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 0.48kg, it offers a good balance of strength and manageability. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 307SFFG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7801 lbf
  • Static Radial Load 5957 lbf
  • Max Speed 9500 rpm
  • Weight 0.48 kg
  • price($) 12.555

Features

Performance Features of 307SFFG Bearing

307SFFG Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 7801 lbf, making it suitable for various industrial applications.

The single-row deep groove design ensures smooth operation and efficient load distribution.
With a maximum speed of 9,500 rpm, it delivers reliable performance in high-speed conditions.

307SFFG Bearing operates in temperatures from -30°C to 120°C, adapting to diverse environments.
Its open seal type allows for easy maintenance and lubrication adjustments when needed.

Application

Industrial Uses of 307SFFG Bearing
307SFFG Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

Where Is 307SFFG Bearing Used?
In automotive applications, 307SFFG Bearing fits well in wheel hubs and alternators, providing smooth rotation under varying speeds. Its chrome steel construction ensures durability even in high-temperature environments.

Perfect Fit for Automation: 307SFFG Bearing
For automated systems, 307SFFG Bearing works reliably in conveyor belts and robotic arms, thanks to its consistent performance. The ABEC 1 tolerance class makes it suitable for general precision requirements.

Light-Duty vs Heavy-Duty: Best Uses for 307SFFG Bearing
In light-duty applications like household appliances, 307SFFG Bearing offers quiet operation and low maintenance. For heavier tasks, it supports radial loads in agricultural equipment without compromising stability.

Medical vs Industrial: Where 307SFFG Bearing Excels
While 307SFFG Bearing isn’t typically used in medical devices, it shines in industrial settings like gearboxes and compressors. Its ISO P0 tolerance ensures reliable performance across various operational conditions.
