Single Row Deep Groove Ball Bearings 214SZZ
Single Row Deep Groove Ball Bearings 214SZZ

Single Row Deep Groove Ball Bearings 214SZZ

The 214SZZ is a single-row deep groove ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14837 lbf and runs smoothly at speeds up to 5600 RPM.

Shielded on both sides, it keeps dirt out while maintaining smooth operation. The chrome steel cage adds durability, making it a reliable choice for long-term use.

This bearing suits temperatures from -30°C to 120°C, fitting well in various industrial settings. It’s interchangeable with SKF models, offering a cost-effective alternative.

Weighing 1.15kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for most applications. Ideal for machinery requiring consistent radial load support.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 214SZZ
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 24 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14837 lbf
  • Static Radial Load 14725 lbf
  • Max Speed 5600 rpm
  • Weight 1.15 kg
  • price($) 26.235

Features

Performance Features of 214SZZ Bearing

214SZZ Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 14837 lbf.
Its shielded design helps protect against contaminants, ensuring smoother operation.

The single-row deep groove construction enhances load distribution, improving durability.
With a maximum speed of 5,600 rpm, it balances performance and longevity.

214SZZ Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its ABEC 1 tolerance ensures reliable precision for various applications.

Application

Industrial Uses of 214SZZ Bearing
214SZZ Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

What Makes 214SZZ Bearing a Preferred Choice?
In automotive applications, 214SZZ Bearing fits well in wheel hubs and transmissions, offering reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard precision needs.

Built for Heavy-Duty Use: 214SZZ Bearing
For automation systems, 214SZZ Bearing works efficiently in conveyor belts and robotic arms. The metric sizing ensures compatibility with a variety of equipment across different industries.

Medical vs Industrial: Where 214SZZ Bearing Excels
While not typically used in medical devices, 214SZZ Bearing shines in industrial settings like gearboxes and compressors. Its temperature range allows for stable performance in varied conditions.
