Single Row Deep Groove Ball Bearings 210SZZST
Single Row Deep Groove Ball Bearings 210SZZST

Single Row Deep Groove Ball Bearings 210SZZST

The 210SZZST is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 8790 lbf and operates smoothly at speeds up to 8000 RPM.

Shielded on both sides, it keeps out dust and debris while maintaining low friction. The chrome steel cage adds durability, making it suitable for continuous use in various conditions.

With a compact width of 20mm, it fits neatly into tight spaces. Ideal for applications like electric motors or conveyor systems where reliable radial load support is needed.

This bearing works in temperatures from -30°C to 120°C and complies with RoHS and REACH standards. Weighing 0.5kg, it offers a good balance of strength and manageability.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 210SZZST
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 8790 lbf
  • Static Radial Load 7756 lbf
  • Max Speed 8000 rpm
  • Weight 0.5 kg

Features

How Does 210SZZST Bearing Reduce Friction?

210SZZST Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while minimising friction during operation.

Its shielded design protects against contaminants, maintaining performance in various environments.
With a dynamic radial load capacity of 8790 lbf, it handles demanding applications with ease.

The ABEC 1 tolerance class guarantees consistent precision, suitable for general industrial use.
Operating temperatures range from -30°C to 120°C, making it versatile for different conditions.

Application

Industrial Uses of 210SZZST Bearing
210SZZST Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

Where Is 210SZZST Bearing Used?
You’ll often find 210SZZST Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable radial load handling. Its ABEC 1 tolerance makes it suitable for general-purpose use.

Perfect Fit for Automation: 210SZZST Bearing
210SZZST Bearing works well in robotic arms and conveyor systems, where smooth operation is key. The shielded seals provide extra protection against dust and debris.

Medical vs Industrial: Where 210SZZST Bearing Excels
In medical devices like centrifuges, 210SZZST Bearing offers quiet and efficient performance. For industrial gearboxes, its robust design handles high radial loads with ease.

Key Fields for 210SZZST Bearing
210SZZST Bearing is a solid choice for household appliances like washing machines, where durability matters. Its temperature range also makes it versatile for various climates.
