The 206SZZST-W64 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4699 lbf and operates smoothly at speeds up to 12,000 RPM.
Its shielded design keeps dirt out while the solid oil lubrication ensures long service life without frequent maintenance. The bearing performs reliably in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for electric motors or pumps where consistent radial load handling is needed.
Weighing 0.21kg, it’s a compact yet durable choice for various industrial applications. Compliant with RoHS and REACH standards for safe usage.
"*" indicates required fields
Performance Features of 206SZZST-W64 Bearing
206SZZST-W64 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4699 lbf.
Its shielded design protects against dust and debris, ensuring smooth operation in various environments.
The solid oil lubrication reduces maintenance needs while extending the bearing’s service life.
With a maximum speed of 12,000 rpm, it delivers reliable performance for high-speed applications.
Common Applications of 206SZZST-W64 Bearing
206SZZST-W64 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its shielded design helps keep contaminants out. The solid oil lubrication ensures smooth operation even in dusty environments.
In automotive applications, 206SZZST-W64 Bearing is often found in alternators and water pumps, providing reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard performance requirements.
For household appliances like washing machines, 206SZZST-W64 Bearing offers quiet and efficient performance. The chrome steel construction ensures durability under everyday use.
Automation systems benefit from 206SZZST-W64 Bearing in conveyor belts and small robotic arms. Its compact size and shielded seals make it ideal for space-constrained applications.
