Single Row Cylindrical Roller Bearings With Inner Ring NUP 2328 ECML
Single Row Cylindrical Roller Bearings With Inner Ring NUP 2328 ECML

Single Row Cylindrical Roller Bearings With Inner Ring NUP 2328 ECML

The NUP 2328 ECML is a single row cylindrical roller bearing with a 140mm bore and 300mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 270,000 lbf and runs smoothly at speeds up to 4000 RPM.

Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures durability and centred roller alignment. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or machinery where combined loads are common.

Weighing 37.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NUP 2328 ECML
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 300 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 102 mm
  • Width Tolerance -0.25mm to 0
  • Shoulder Dia Of Inner Ring 195 mm
  • Chamfer Dimension r1,2(min.) 4 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 270000 lbf
  • Static Radial Load 321750 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 37.1 kg
  • Shoulder Dia Of Outer Ring 251.7 mm
  • Raceway Diameter Of Inner Ring 180 mm
  • Chamfer Dimension Of Loose Flange Ring(r3,4)(min.) 4 mm

Features

Performance Features of NUP 2328 ECML Bearing

NUP 2328 ECML Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 270,000 lbf, making it suitable for heavy-duty applications.

The PA66 cage keeps the rollers centred, ensuring smooth operation and reducing friction.
This design enhances the bearing’s durability and extends its service life.

NUP 2328 ECML Bearing operates efficiently in temperatures ranging from -30° to 110°C.
With a maximum speed of 4,000 rpm, it balances performance and reliability in demanding conditions.

The open seal design allows for easy lubrication with grease or oil.
This feature simplifies maintenance and ensures consistent performance over time.

Application

Industrial Uses of NUP 2328 ECML Bearing
NUP 2328 ECML Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its cylindrical roller design handles combined loads efficiently. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, NUP 2328 ECML Bearing supports components such as truck transmissions and differential systems, providing reliable performance under high radial loads. Its metric sizing makes it a versatile choice for various vehicle designs.

For automation equipment, NUP 2328 ECML Bearing’s high-speed capability (up to 4000 rpm) makes it suitable for robotic arms and precision machinery. The PA66 cage helps reduce friction, enhancing smooth operation in repetitive tasks.

Where Is NUP 2328 ECML Bearing Used?
NUP 2328 ECML Bearing finds its place in wind turbines, where its ability to handle both radial and axial loads ensures stable operation. The open seal design allows for easy lubrication, extending service life.

In construction equipment, NUP 2328 ECML Bearing is often found in crane slewing rings, thanks to its robust build and high static load capacity. The temperature range (-30° to 110°C) ensures reliability in varying weather conditions.

Built for Heavy-Duty Use: NUP 2328 ECML Bearing
NUP 2328 ECML Bearing is ideal for steel mills, where its chrome steel rollers withstand extreme loads and harsh conditions. The single-row design simplifies installation and maintenance.

For mining machinery, NUP 2328 ECML Bearing’s high dynamic radial load capacity (270000 lbf) makes it a dependable choice for crushers and excavators. The grease or oil lubrication options adapt to different operational needs.

Automotive vs Aerospace: Applications of NUP 2328 ECML Bearing
In automotive systems, NUP 2328 ECML Bearing is used in heavy-duty axles, offering stability under high stress. Its compatibility with SKF models makes it a cost-effective replacement.

For aerospace ground equipment, NUP 2328 ECML Bearing’s precision engineering ensures smooth operation in aircraft tow tractors and loading systems. The wide temperature range suits diverse working environments.
