Single Row Cylindrical Roller Bearings With Inner Ring NUP 2326 ECML
Single Row Cylindrical Roller Bearings With Inner Ring NUP 2326 ECML

Single Row Cylindrical Roller Bearings With Inner Ring NUP 2326 ECML

The NUP 2326 ECML is a single row cylindrical roller bearing with a 130mm bore and 280mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 238500 lbf and operates smoothly at speeds up to 4000 RPM.

Its open design allows for easy lubrication with grease or oil, while the PA66 cage ensures durability and centred roller alignment. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or gearboxes where combined loads are common.

Weighing 29.5kg, it’s built to withstand demanding conditions while complying with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NUP 2326 ECML
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 93 mm
  • Width Tolerance -0.25mm to 0
  • Shoulder Dia Of Inner Ring 181 mm
  • Chamfer Dimension r1,2(min.) 4 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 238500 lbf
  • Static Radial Load 281250 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 29.5 kg
  • Shoulder Dia Of Outer Ring 235.2 mm
  • Raceway Diameter Of Inner Ring 167 mm
  • Chamfer Dimension Of Loose Flange Ring(r3,4)(min.) 4 mm

Features

Performance Features of NUP 2326 ECML Bearing

NUP 2326 ECML Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 238,500 lbf, making it suitable for heavy-duty applications.

The PA66 cage keeps the rollers centred, ensuring smooth operation and reduced wear.
With a maximum speed of 4,000 rpm, it delivers reliable performance in various conditions.

NUP 2326 ECML Bearing operates efficiently within a temperature range of -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, enhancing longevity.

The precise dimensions and tolerances ensure a perfect fit in demanding industrial setups.
This bearing is interchangeable with SKF models, providing flexibility in replacements.

Application

Industrial Uses of NUP 2326 ECML Bearing
NUP 2326 ECML Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles both radial and axial loads effectively. The chrome steel construction ensures durability even in demanding environments.

Where Is NUP 2326 ECML Bearing Used?
You’ll often find NUP 2326 ECML Bearing in wind turbines and mining equipment, thanks to its ability to withstand high dynamic loads. The PA66 cage keeps the rollers centred, reducing friction and wear over time.

Built for Heavy-Duty Use: NUP 2326 ECML Bearing
NUP 2326 ECML Bearing excels in applications like steel mills and paper processing machines, where its high load capacity and temperature resistance are key. The open design allows for easy lubrication, extending its service life.

Automotive vs Aerospace: Applications of NUP 2326 ECML Bearing
In automotive systems, NUP 2326 ECML Bearing supports components like drivetrains, while in aerospace, it’s used in auxiliary systems. Its metric sizing makes it versatile for various industrial and transportation needs.

Perfect Fit for Automation: NUP 2326 ECML Bearing
NUP 2326 ECML Bearing is ideal for robotic arms and automated production lines, where precision and reliability are crucial. The combined load handling capability ensures smooth operation in repetitive motion scenarios.
