The NUP 212 ECP is a single row cylindrical roller bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 24300 lbf and runs smoothly at speeds up to 8000 RPM.
Its open design allows easy lubrication with grease or oil, while the PA66 cage keeps rollers centred for reliable performance. The bearing operates well in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery requiring combined load support, such as gearboxes or industrial equipment.
Weighing 0.86kg, it offers a robust yet manageable size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of NUP 212 ECP Bearing
NUP 212 ECP Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 24,300 lbf, making it suitable for demanding industrial applications.
The PA66 cage keeps the rollers centred, ensuring smooth operation and reduced wear.
With a maximum speed of 8,000 rpm, it delivers reliable performance under high-speed conditions.
NUP 212 ECP Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, extending service life.
The precise chamfer dimensions of 1.5 mm ensure proper fit and alignment during installation.
This bearing is interchangeable with SKF models, providing flexibility in replacement options.
Industrial Uses of NUP 212 ECP Bearing
NUP 212 ECP Bearing is commonly used in machine tools, where its cylindrical roller design handles both radial and axial loads efficiently. The open seal type allows for easy lubrication, making it suitable for high-speed operations.
In automotive applications, NUP 212 ECP Bearing fits well in gearboxes and transmission systems, providing reliable performance under combined loads. Its chrome steel construction ensures durability even in demanding conditions.
For automation systems, NUP 212 ECP Bearing supports robotic arms and conveyor belts, where precision and smooth movement are key. The PA66 cage material reduces friction, enhancing overall efficiency.
Where Is NUP 212 ECP Bearing Used?
NUP 212 ECP Bearing finds its place in industrial fans and blowers, where its high dynamic radial load capacity ensures long service life. The metric dimensions make it compatible with a wide range of machinery.
In medical imaging devices, NUP 212 ECP Bearing offers quiet and stable operation, crucial for accurate diagnostics. The temperature range of -30° to 110°C makes it versatile for various environments.
Built for Heavy-Duty Use: NUP 212 ECP Bearing
NUP 212 ECP Bearing is ideal for construction equipment, handling heavy loads with ease. Its robust design and chrome steel rollers provide excellent wear resistance.
In printing machinery, NUP 212 ECP Bearing ensures smooth paper feed and consistent performance. The grease or oil lubrication options allow for flexibility in maintenance.
Automotive vs Aerospace: Applications of NUP 212 ECP Bearing
In automotive engines, NUP 212 ECP Bearing supports crankshafts and camshafts, ensuring smooth rotation. Its high-speed capability up to 8000 rpm makes it a reliable choice.
For aerospace applications, NUP 212 ECP Bearing is used in auxiliary systems where precision and reliability are paramount. The lightweight PA66 cage contributes to overall weight reduction.
