The NU 316 ECM is a single-row cylindrical roller bearing with an 80mm bore and 170mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 67500 lbf and runs smoothly at speeds up to 5000 RPM.
Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.
With a width of 39mm and chamfered edges, it fits snugly in tight spaces. Ideal for heavy-duty applications like industrial gearboxes or machinery shafts where radial and axial loads are present.
Weighing 4.39kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF bearings.
"*" indicates required fields
Performance Features of NU 316 ECM Bearing
NU 316 ECM Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 67,500 lbf, ensuring reliable performance in heavy-duty applications.
The brass cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 5,000 rpm, it balances durability and efficiency in various conditions.
NU 316 ECM Bearing operates smoothly in temperatures from -30° to 110°C, making it versatile for different environments.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The precise chamfer dimensions of 2.1 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high radial load capacity and long service life.
Industrial Uses of NU 316 ECM Bearing
NU 316 ECM Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently. The brass cage ensures smooth operation even at high speeds up to 5000 rpm.
What Makes NU 316 ECM Bearing a Preferred Choice?
In automotive applications, NU 316 ECM Bearing fits well in truck wheel hubs and transmission systems due to its robust chrome steel construction. Its open design allows for easy lubrication, extending service life in demanding conditions.
Perfect Fit for Automation: NU 316 ECM Bearing
For automated production lines, NU 316 ECM Bearing supports conveyor rollers and robotic arms with reliable performance. The metric dimensions make it compatible with standard European equipment, reducing downtime during replacements.
Medical vs Industrial: Where NU 316 ECM Bearing Excels
While not typically used in medical devices, NU 316 ECM Bearing shines in industrial settings like paper mills and mining equipment. Its high dynamic radial load capacity (67500 lbf) ensures durability in harsh environments.
Essential Roles of NU 316 ECM Bearing
In wind turbine generators, NU 316 ECM Bearing handles combined loads while withstanding temperature variations from -30° to 110°C. The grease or oil lubrication options provide flexibility for different maintenance schedules.
