The NU 234 ECM is a single-row cylindrical roller bearing with a 170mm bore and 310mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 156375 lbf and runs smoothly at speeds up to 2000 RPM.
Its brass cage keeps rollers centred for even load distribution, while the open design allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.
With a 52mm width and chamfered edges, it fits snugly in tight spaces. Ideal for heavy machinery like gearboxes or industrial pumps where radial and axial loads are present.
Weighing 17.7kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacements.
"*" indicates required fields
Performance Features of NU 234 ECM Bearing
NU 234 ECM Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 156375 lbf, ensuring reliable performance in heavy-duty applications.
The brass cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 2000 rpm, it balances durability and efficiency in demanding conditions.
NU 234 ECM Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The precise chamfer dimensions of 4 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high radial load capacity and long service life.
Industrial Uses of NU 234 ECM Bearing
NU 234 ECM Bearing is commonly used in heavy machinery like industrial gearboxes and large conveyor systems, where its cylindrical roller design handles high radial loads efficiently. The brass cage ensures smooth operation even at speeds up to 2000 rpm.
What Makes NU 234 ECM Bearing a Preferred Choice?
In automotive applications, NU 234 ECM Bearing supports components such as wheel hubs and transmissions, thanks to its robust chrome steel construction. Its metric sizing makes it a reliable fit for various vehicle designs.
Built for Heavy-Duty Use: NU 234 ECM Bearing
For wind turbines and mining equipment, NU 234 ECM Bearing’s ability to withstand combined loads makes it ideal. The open seal design allows for easy lubrication, extending service life in harsh conditions.
Automotive vs Aerospace: Applications of NU 234 ECM Bearing
While NU 234 ECM Bearing excels in automotive drivetrains, it’s also found in aerospace landing gear systems. Its high dynamic radial load capacity ensures performance in both demanding environments.
Perfect Fit for Automation: NU 234 ECM Bearing
In robotic assembly lines, NU 234 ECM Bearing provides precise movement for robotic arms and linear actuators. The roller-centred brass cage reduces friction, enhancing accuracy and longevity.
