The NU 2215 ECP is a single-row cylindrical roller bearing with a 75mm bore and 130mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 41850 lbf and operates smoothly at speeds up to 6000 RPM.
Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures stable performance. The bearing works well in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like industrial machinery or gearboxes where radial and axial loads are present.
Weighing 1.56kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of NU 2215 ECP Bearing
NU 2215 ECP Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 41,850 lbf, ensuring reliable performance in demanding conditions.
The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 6,000 rpm, it balances durability and efficiency.
Why Choose NU 2215 ECP Bearing for Precision Tasks?
NU 2215 ECP Bearing features precise dimensions with a bore diameter of 75 mm and outer diameter of 130 mm.
Its chrome steel construction ensures smooth operation even under high radial loads.
The open design allows for easy lubrication with grease or oil, enhancing performance.
With a temperature range of -30° to 110°C, it adapts to various working environments.
Engineered for Reliability: NU 2215 ECP Bearing
NU 2215 ECP Bearing’s single-row cylindrical design provides excellent radial load capacity.
The chrome steel rollers and rings ensure durability and long service life.
Its permissible axial displacement of 1.7 mm accommodates slight misalignments.
Weighing just 1.56 kg, it offers a lightweight yet robust solution for industrial applications.
How Does NU 2215 ECP Bearing Resist Wear?
NU 2215 ECP Bearing’s chrome steel rollers and rings are designed to minimise wear.
The PA66 cage reduces friction, ensuring smooth operation over extended periods.
With a static radial load capacity of 46,800 lbf, it handles heavy loads effortlessly.
Its open seal type allows for easy maintenance, further enhancing longevity.
Optimized for Efficiency: NU 2215 ECP Bearing
NU 2215 ECP Bearing’s precise engineering ensures low friction and high efficiency.
The roller-centred design enhances load distribution, reducing stress on components.
Its wide temperature range makes it suitable for diverse industrial applications.
With interchangeable compatibility with SKF bearings, it offers flexibility in replacements.
Industrial Uses of NU 2215 ECP Bearing
NU 2215 ECP Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, making it suitable for continuous operation in demanding environments.
Where Is NU 2215 ECP Bearing Used?
In automotive applications, NU 2215 ECP Bearing can be found in wheel hubs and transmissions, providing reliable performance under combined loads. Its chrome steel construction ensures durability even in high-speed scenarios, up to 6000 rpm.
Built for Heavy-Duty Use: NU 2215 ECP Bearing
NU 2215 ECP Bearing excels in conveyor systems and mining equipment, where its PA66 cage reduces friction and wear. The metric dimensions make it a versatile choice for various industrial setups across different regions.
Automotive vs Industrial: Applications of NU 2215 ECP Bearing
NU 2215 ECP Bearing is equally at home in both automotive and industrial settings, from truck axles to paper mill rollers. Its wide temperature range (-30° to 110°C) ensures consistent performance in diverse operating conditions.
Perfect Fit for Automation: NU 2215 ECP Bearing
NU 2215 ECP Bearing works well in robotic arms and automated assembly lines, where precision and load capacity are key. The single-row design simplifies installation while maintaining high radial load capacity.
