The NU 2215 ECML is a single row cylindrical roller bearing with a 75mm bore and 130mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 41850 lbf and reaches speeds of 10000 RPM.
Its brass cage design ensures smooth operation, while the open seal allows for easy lubrication with grease or oil. The bearing performs reliably in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or machinery where radial and axial loads are present.
Weighing 1.74kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.
"*" indicates required fields
Performance Features of NU 2215 ECML Bearing
NU 2215 ECML Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 41,850 lbf, ensuring reliable performance in demanding conditions.
The brass cage design keeps the rollers aligned, reducing friction and extending service life.
With a maximum speed of 10,000 rpm, it balances durability and efficiency for high-speed applications.
NU 2215 ECML Bearing operates effectively in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The precise chamfer dimensions of 1.5 mm ensure smooth installation and operation.
This bearing is ideal for applications requiring high radial load capacity and long-lasting performance.
Industrial Uses of NU 2215 ECML Bearing
NU 2215 ECML Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently. The brass cage ensures smooth operation even at speeds up to 10,000 rpm.
Where Is NU 2215 ECML Bearing Used?
In automotive applications, NU 2215 ECML Bearing supports components such as wheel hubs and transmissions, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle designs.
Perfect Fit for Automation: NU 2215 ECML Bearing
NU 2215 ECML Bearing works well in robotic arms and automated production lines, where precision and durability are key. The open seal design allows for easy lubrication, extending its service life in continuous operation.
Medical vs Industrial: Where NU 2215 ECML Bearing Excels
NU 2215 ECML Bearing is ideal for industrial equipment like pumps and compressors, but its high-speed capability also suits medical centrifuges. The temperature range of -30° to 110°C ensures reliability in diverse environments.
Key Fields for NU 2215 ECML Bearing
NU 2215 ECML Bearing is a go-to for wind turbine generators, where its ability to handle combined loads is crucial. The grease or oil lubrication options make it adaptable to different maintenance schedules.
