The NU 2207 ECML is a single-row cylindrical roller bearing with a 35mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 15638 lbf and spins smoothly at speeds up to 18000 RPM.
Its brass cage design ensures stable performance, while the open seal allows easy lubrication with grease or oil. The bearing operates well in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or industrial machinery where radial and axial loads are present.
Weighing just 0.45kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of NU 2207 ECML Bearing
NU 2207 ECML Bearing is constructed with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 15638 lbf, ensuring reliable performance in demanding conditions.
The brass cage design keeps the rollers aligned, reducing friction and extending service life.
With a maximum speed of 18000 rpm, it balances durability and efficiency for high-speed applications.
NU 2207 ECML Bearing operates effectively in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.
The precise chamfer dimensions of 1.1 mm and 0.6 mm ensure smooth installation and operation.
This bearing is interchangeable with SKF models, providing flexibility in replacements.
Industrial Uses of NU 2207 ECML Bearing
NU 2207 ECML Bearing is commonly used in industrial machinery like pumps and compressors, where its cylindrical roller design handles both radial and axial loads efficiently. The brass cage ensures smooth operation even at high speeds up to 18000 rpm.
Where Is NU 2207 ECML Bearing Used?
You’ll often find NU 2207 ECML Bearing in automotive transmissions, where its 35mm bore fits standard shafts perfectly. The chrome steel construction provides durability under heavy loads while maintaining precise alignment.
Built for Heavy-Duty Use: NU 2207 ECML Bearing
NU 2207 ECML Bearing works well in conveyor systems that require continuous operation. Its open design allows for easy lubrication, extending service life in demanding environments.
Automotive vs Industrial: Applications of NU 2207 ECML Bearing
In automotive applications, NU 2207 ECML Bearing supports gearboxes, while in industrial settings it’s ideal for electric motors. The metric sizing makes it versatile across different equipment types.
Perfect Fit for Automation: NU 2207 ECML Bearing
NU 2207 ECML Bearing performs reliably in robotic arms and automated assembly lines. The combined load capacity ensures stability during repetitive movements and precision tasks.
