Single Row Cylindrical Roller Bearings With Inner Ring NU 220 ECP
Single Row Cylindrical Roller Bearings With Inner Ring NU 220 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NU 220 ECP

The NU 220 ECP is a single row cylindrical roller bearing with a 100mm bore and 180mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 64125 lbf and runs smoothly at speeds up to 4000 RPM.

Its open design allows easy lubrication with grease or oil, while the PA66 cage ensures reliable performance. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like industrial gearboxes or heavy machinery where radial and axial loads are present.

Weighing 3.46kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NU 220 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 100 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 34 mm
  • Width Tolerance -0.20mm to 0
  • Chamfer Dimension r1,2(min.) 2.1 mm
  • Chamfer Dimension r3,4(min.) 2.1 mm
  • Permissible Axial Displacement(max.) 1.7 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 64125 lbf
  • Static Radial Load 68625 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 3.46 kg
  • Shoulder Dia Of Outer Ring 155.55 mm
  • Raceway Diameter Of Inner Ring 119 mm

Features

Performance Features of NU 220 ECP Bearing

NU 220 ECP Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 64,125 lbf, ensuring reliable performance in demanding conditions.

The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 4,000 rpm, it balances durability and efficiency.

NU 220 ECP Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 2.1 mm ensure easy installation and alignment.
This makes NU 220 ECP Bearing a practical choice for various industrial applications.

Application

Industrial Uses of NU 220 ECP Bearing
NU 220 ECP Bearing is commonly used in heavy machinery like industrial gearboxes and large electric motors, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, extending service life in demanding conditions.

Where Is NU 220 ECP Bearing Used?
In automotive applications, NU 220 ECP Bearing supports components such as wheel hubs and transmissions, thanks to its robust chrome steel construction. Its metric sizing ensures compatibility with a variety of vehicle designs.

Perfect Fit for Automation: NU 220 ECP Bearing
NU 220 ECP Bearing works well in automated systems like conveyor belts and robotic arms, where precise movement is essential. The PA66 cage material reduces friction, ensuring smooth operation at high speeds.

Medical vs Industrial: Where NU 220 ECP Bearing Excels
While NU 220 ECP Bearing is ideal for industrial equipment like pumps and compressors, its reliability also makes it suitable for medical imaging devices. The temperature range of -30° to 110°C ensures performance in diverse environments.

Essential Roles of NU 220 ECP Bearing
NU 220 ECP Bearing is a go-to choice for wind turbines and other renewable energy systems, where durability under combined loads is critical. Its high dynamic radial load capacity ensures long-term reliability.
