The NU 210 ECJ is a single-row cylindrical roller bearing with a 50mm bore and 90mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 16538 lbf and operates smoothly at speeds up to 9000 RPM.
Its open design allows for easy lubrication with grease or oil, while the steel cage ensures stable roller alignment. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
With a compact width of 20mm, it fits well in tight spaces. The chamfered edges (1.1mm) help with easy installation. Ideal for applications like electric motors or gearboxes where radial and axial loads are present.
Weighing 0.49kg, it’s a sturdy yet manageable choice. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for convenient replacements.
"*" indicates required fields
Performance Features of NU 210 ECJ Bearing
NU 210 ECJ Bearing is crafted with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 16538 lbf, ensuring reliable performance in demanding conditions.
The steel cage keeps the rollers centred, reducing wear and extending operational life.
With a maximum speed of 9000 rpm, it balances durability and efficiency for various applications.
NU 210 ECJ Bearing operates smoothly in temperatures from -30° to 110 °C, making it versatile.
Its open design allows for easy lubrication with grease or oil, simplifying maintenance.
Industrial Uses of NU 210 ECJ Bearing
NU 210 ECJ Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its cylindrical roller design handles high radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.
In automotive applications, NU 210 ECJ Bearing fits well in gearboxes and wheel hubs, providing reliable performance under combined loads. Its metric sizing ensures compatibility with a variety of vehicle designs, making it a versatile choice.
For automation equipment, NU 210 ECJ Bearing supports smooth operation in robotic arms and assembly lines. The steel cage design enhances stability, even at high speeds up to 9000 rpm.
Medical devices like diagnostic scanners benefit from NU 210 ECJ Bearing’s precision and durability. The chrome steel construction ensures consistent performance in critical healthcare environments.
In household appliances such as washing machines, NU 210 ECJ Bearing offers quiet and efficient operation. Its grease or oil lubrication options make it adaptable to different maintenance needs.
