Single Row Cylindrical Roller Bearings With Inner Ring NU 2080 ECMA
Single Row Cylindrical Roller Bearings With Inner Ring NU 2080 ECMA

Single Row Cylindrical Roller Bearings With Inner Ring NU 2080 ECMA

The NU 2080 ECMA is a single row cylindrical roller bearing with a 400mm bore and 600mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 544500 lbf and operates smoothly at speeds up to 1000 RPM.

Its brass cage and open design ensure reliable performance, while the inner ring provides stability. The bearing works well in temperatures from -30°C to 110°C and can be lubricated with grease or oil.

With a weight of 128kg, it’s built for heavy-duty applications like industrial machinery or large gearboxes. Compliant with RoHS and REACH standards, it’s a safe and sturdy choice for demanding environments.

This model is interchangeable with SKF bearings, making it a practical option for replacements or upgrades. The 5mm chamfer dimension ensures easier installation and alignment.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number NU 2080 ECMA
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 400 mm
  • Bore Dia Tolerance -0.04mm to 0
  • Outer Dia 600 mm
  • Outer Dia Tolerance -0.05mm to 0
  • Width 118 mm
  • Width Tolerance -0.40mm to 0
  • Chamfer Dimension r1,2(min.) 5 mm
  • Permissible Axial Displacement(max.) 9.9 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass cage, outer ring centred
  • Dynamic Radial Load 544500 lbf
  • Static Radial Load 1023750 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 1000 rpm
  • Weight 128 kg
  • Shoulder Dia Of Outer Ring 536 mm
  • Raceway Diameter Of Inner Ring 449 mm

Features

Performance Features of NU 2080 ECMA Bearing

NU 2080 ECMA Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 544,500 lbf, ensuring reliable performance in heavy-duty applications.

The brass cage keeps the rollers aligned, reducing wear and extending service life.
With a maximum speed of 1,000 rpm, it balances durability and efficiency in demanding conditions.

NU 2080 ECMA Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 5 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high load capacity and long service life.

Application

Industrial Uses of NU 2080 ECMA Bearing
NU 2080 ECMA Bearing is commonly used in heavy machinery like rolling mills and large gearboxes, where its high radial load capacity is essential. The brass cage design helps reduce friction, making it suitable for continuous operation.

In automotive applications, NU 2080 ECMA Bearing supports large drivetrain components, handling both radial and axial loads with ease. Its chrome steel construction ensures longevity even under demanding conditions.

For industrial fans and blowers, NU 2080 ECMA Bearing’s open design allows for efficient lubrication, maintaining performance at high speeds. The metric sizing ensures compatibility with a wide range of equipment.

Where Is NU 2080 ECMA Bearing Used?
NU 2080 ECMA Bearing finds its place in construction equipment, such as cranes and excavators, where durability and load capacity are critical. Its robust design handles the stresses of heavy lifting effortlessly.

In power generation, NU 2080 ECMA Bearing is often seen in turbines and generators, providing reliable support under high radial loads. The temperature range makes it adaptable to various operating environments.

Built for Heavy-Duty Use: NU 2080 ECMA Bearing
NU 2080 ECMA Bearing excels in mining equipment, where its ability to handle combined loads is invaluable. The large bore diameter accommodates heavy shafts commonly found in this industry.

For paper manufacturing machinery, NU 2080 ECMA Bearing’s grease or oil lubrication options ensure smooth operation. Its static radial load capacity makes it a dependable choice for high-pressure applications.
