The NU 206 ECJ is a single row cylindrical roller bearing with a 30mm bore and 62mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 9900 lbf and spins smoothly at speeds up to 14000 RPM.
Its open design allows easy lubrication with grease or oil, while the steel cage ensures stable performance. The bearing operates well in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial and axial loads are present.
Weighing just 0.21kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.
"*" indicates required fields
Performance Features of NU 206 ECJ Bearing
NU 206 ECJ Bearing is designed with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 9900 lbf, ensuring reliable performance in various applications.
The steel cage keeps the rollers centred, reducing wear and extending service life.
With a maximum speed of 14,000 rpm, it balances durability and efficiency.
How Does NU 206 ECJ Bearing Reduce Friction?
NU 206 ECJ Bearing’s precision-engineered rollers and raceways minimise friction during operation.
The chrome steel materials and centred cage design ensure smooth movement under heavy loads.
This design also helps in reducing heat generation, enhancing overall performance.
Suitable for both grease and oil lubrication, it adapts to different working conditions.
Engineered for Precision: NU 206 ECJ Bearing
NU 206 ECJ Bearing is crafted for high-precision applications with tight tolerances.
Its bore diameter tolerance ranges from -0.01mm to 0, ensuring a precise fit.
The chamfer dimensions of 1 mm and 0.6 mm facilitate easy installation.
This bearing operates efficiently within a temperature range of -30° to 110 °C.
Why Choose NU 206 ECJ Bearing for Combined Loads?
NU 206 ECJ Bearing handles both radial and axial loads effectively.
Its static radial load capacity of 8212 lbf ensures stability under pressure.
The permissible axial displacement of 1.3 mm allows for slight misalignments.
This makes it a versatile choice for various industrial applications.
Built for Reliability: NU 206 ECJ Bearing
NU 206 ECJ Bearing’s robust construction ensures long-term reliability.
The chrome steel rollers and rings resist wear, even in demanding conditions.
With a weight of 0.21 kg, it offers a balance between strength and portability.
Its compliance with RoHS and REACH standards guarantees environmental safety.
Industrial Uses of NU 206 ECJ Bearing
NU 206 ECJ Bearing is commonly used in machine tools, where its cylindrical roller design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.
In automotive applications, NU 206 ECJ Bearing fits well in gearboxes and drivetrains, providing reliable performance under combined loads. Its metric sizing ensures compatibility with a variety of vehicle designs.
For automation systems, NU 206 ECJ Bearing supports robotic arms and conveyor belts, thanks to its high-speed capability. The chrome steel construction ensures durability even in continuous operation.
Where Is NU 206 ECJ Bearing Used?
NU 206 ECJ Bearing can be found in industrial fans, where its ability to handle radial loads keeps operations smooth. The steel cage design adds stability, reducing vibration during high-speed rotation.
In medical imaging devices, NU 206 ECJ Bearing offers precise movement, crucial for accurate diagnostics. Its temperature range makes it suitable for various clinical environments.
Built for Heavy-Duty Use: NU 206 ECJ Bearing
NU 206 ECJ Bearing excels in construction equipment, where its robust design withstands heavy loads. The grease or oil lubrication options provide flexibility for different working conditions.
In printing machinery, NU 206 ECJ Bearing ensures consistent paper feed with minimal friction. Its high max speed rating makes it ideal for fast-paced production lines.
Automotive vs Aerospace: Applications of NU 206 ECJ Bearing
In automotive systems, NU 206 ECJ Bearing is often used in wheel hubs, where its radial load capacity is essential. The metric dimensions align with standard automotive components.
For aerospace applications, NU 206 ECJ Bearing supports auxiliary systems, benefiting from its high-speed performance. The chrome steel material meets the industry’s durability requirements.
